Chapter 1 — General Information
Table 1-2. Test Equipment Required for Verifying Spectrum Analyzer Functions up to 40 GHz
Instrument
Synthesized Signal Generator
Synthesized Signal Generator
Power Meter
Power Sensor
50 ohm Termination
Adapter
Adapter
RF Coaxial Cable
Lowpass Filter
Frequency Reference
Signal Generator
Fixed Attenuator
Fixed Attenuator
Fixed Attenuator
Fixed Attenuator
Fixed Attenuator
Power Splitter
Power Splitter
Coaxial Cable
Adapter
b. Note that MG3692A models require Option 15 to achieve power of +16 dBm at 3.5 GHz. MG3692B models do not require
Option 15 to achieve power of +16 dBm at 3.5 GHz.
Factory tests have shown that the equipment that is listed above will provide satisfactory results at
Caution 43 GHz (the upper limit of the MS2726C) even though the chart above specifies 40 GHz
(per manufacturers specifications).
MS272xC MM
Critical Specification
Frequency: 0.1 Hz to 20 GHz,
Power Output: +16 dBm,
Step attenuator installed
Frequency: 0.1 Hz to 40 GHz,
Power Output: +16 dBm,
Step attenuator installed
Power Range: –70 to +20 dBm
Frequency: 100 kHz to 40 GHz
Power Range: –70 to +20 dB
Frequency: DC to 40 GHz
Frequency: DC to 40 GHz
K(m)-K(m), 50 ohm
Frequency: DC to 40 GHz
K(f)-K(f), 50 ohm
Frequency: DC to 40 GHz
K(m)-K(f), 50 ohm
Frequency: 50 MHz
Frequency: 10 MHz
10 dB Attenuation
10 dB Attenuation
20 dB Attenuation
6 dB Attenuation
2 dB Attenuation
Frequency: DC to 18 GHz
Frequency: DC to 40 GHz
BNC(m) to BNC(m), 50 ohm
K(f) to N(f), 50 ohms, Ruggedized
PN: 10580-00279 Rev. E
1-3 Recommended Test Equipment
Recommended Manufacturer/Model
Anritsu Model MG3692A or MG3692B
with Options 2A, 4, 22, 15x
Anritsu Model MG3692A or MG3695C
with Options 2A, 4, 22, 15x
Anritsu Model ML2438A
Anritsu Model SC7413 (Qty 2) K type
Anritsu Model 28KF50-2
Anritsu Model K220B
Anritsu Model K222B
Anritsu Model 3670K50-2 (Qty 2)
Anritsu Part Number 1030-96
Symmetricom RubiSource T&M
Agilent Model 8648D with Options 1ES
and 1EA
Aeroflex/Weinschel Model 44-10
(Qty 2)
Anritsu Model 41KC-10
Aeroflex/Weinschel Model 44-20
(Qty 2)
Aeroflex/Weinschel Model 44-6 (Qty 2)
Aeroflex/Weinschel Model 44-2 (Qty 2)
Aeroflex/Weinschel Model 1870A
Anritsu Model K241C
Any (Qty 2)
Anritsu Model 71693-R
b
b
