Chapter 4 — Battery Information
3. Remove the battery access door as shown
Figure 4-3. Removing the Battery Access Door
4. With the battery access door completely removed, grasp the battery lanyard and pull the battery straight
out of the unit, as illustrated in
Figure 4-4. Removing the Battery
MS272xC MM
Figure 4-3.
Slide Battery Access Door
Down and Remove.
Figure 4-4.
PN: 10580-00279 Rev. E
4-2 Battery Pack Removal and Replacement
4-3
