Chapter 1 — General Information
Table 1-3. Test Equipment Required for Verifying Functions of Installed Options (2 of 2)
Instrument
GPS Antenna
Coaxial Cable
Adapter
c. Note that MG3692A models require Option 15 to achieve power of +13 dBm. MG3692B models do not require Option 15 to
achieve +13 dBm power.
d Note that the MG3700A requires that several factory custom test pattern files be installed into its memory.
1-4

Replaceable Parts

Table 1-4. List of Replaceable Parts (1 of 2)
Part Number
ND72062
ND72063
ND72064
ND72065
ND72066
ND72070
ND72069
ND72068
ND70320
3-790-661
3-15-154
3-61368
2000-1685-R
3-68100-1
3-61365-1
ND69107
3-65314
3-65316
3-65684
3-68108
3-68107
3-68106
3-68105
3-68104
61379-1
633-75
510-87
3-71353
MS272xC MM
Critical Specification
BNC(m) to BNC(m), 50 ohm
K(f) to N(f), 50 ohms, Ruggedized
MS2722C Main PCB Assembly, with Option 9
MS2723C Main PCB Assembly, with Option 9
MS2724C Main PCB Assembly, with Option 9
MS2725C Main PCB Assembly, with Option 9
MS2726C Main PCB Assembly, with Option 9
MS2725C and MS2726C Spec Analyzer PCB Assembly
MS2724C Spec Analyzer PCB Assembly
MS2722C and MS2723C Spec Analyzer PCB Assembly
MS272xC GPS Receiver PCB (Option 31)
Gasket material for case edge
LCD Display
Clear Plastic LCD Protector
Soft Carrying Case
Case Top (excludes model ID Label and keypad items)
Case Bottom (excluding Tilt Bail)
Case Bottom including Tilt Bail
Left and Right Tilt Bail (Plastic) Holders
Tilt Bail Stand (Metal)
Tilt Bail (Plastic) Clip
Model MS2722C ID Label
Model MS2723C ID Label
Model MS2724C ID Label
Model MS2725C ID Label
Model MS2726C ID Label
Battery Door
High Capacity Li-ion Battery Pack
Type N RF Input connector
Type K(m) Rugged RF Input connector
PN: 10580-00279 Rev. E
Recommended Manufacturer/Model
Anritsu 2000-1410
Any
Anritsu Model 71693-R
Description
e
e
e
e
e
