Appendix A — Test Records
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________

Option 541 and Option 543 LTE Measurements

Table A-126. Option 541 and Option 543, LTE Channel Power Accuracy
Frequency Input Power
(MHz) (dBm)
750
750
2150
2150
750
750
2150
2150
MS272xC MM
Options: __________________________________________________
Measured
Channel Power
For Units with Option 541 Installed, Pattern E-TM_1-1_10M
–10
–50
–10
–50
For Units with Option 543 Installed, Pattern E-TM_1-1_20M
–10
–50
–10
–50
PN: 10580-00279 Rev. E
A-3 Test Records for Options Verification
Error
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
Date: ____________
Specification
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
± 1.5 dB
dB
A-53
