Appendix A — Test Records
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________
Option 40, GSM/GPRS/EDGE RF Measurements
Table A-71. Option 40, At 850 MHz, –50 dBm Level, DL_MCS-9_4SLOT Pattern (EDGE)
Measurement
Adjusted Output Power
Displayed Burst Power
Calculated Burst Power Error
Frequency Error
Table A-72. Option 40, At 850 MHz, –10 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)
Measurement
Adjusted Output Power
Displayed Burst Power
Calculated Burst Power Error
Frequency Error
MS272xC MM
Options: __________________________________________________
(Continued)
Measured Value
Measured Value
PN: 10580-00279 Rev. E
A-3 Test Records for Options Verification
Date: ____________
dB
dB
dB
Hz
dB
dB
dB
Hz
Specification
–10 dBm ± 0.2 dB
± 1.5 dB
± 10 Hz
Specification
–10 dBm ± 0.2 dB
± 1.5 dB
± 10 Hz
A-37
