Appendix A — Test Records
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________

Option 66 Mobile WiMAX RF Measurements (Continued)

Channel Power Accuracy (5 MHz Bandwidth and 5 ms Frame Length)
Table A-118. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –15.0 dBm)
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-119. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –50.0 dBm)
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-120. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –15.0 dBm)
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-121. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –50.0 dBm)
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
MS272xC MM
Options: __________________________________________________
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00279 Rev. E
A-3 Test Records for Options Verification
Date: ____________
dBm
dBm
dB
dBm
dBm
dB
dBm
dBm
dB
dBm
dBm
dB
Specification
–15 dBm ± 0.2 dB
± 1.5 dB
Specification
–50 dBm ± 0.2 dB
± 1.5 dB
Specification
–15 dBm ± 0.2 dB
± 1.5 dB
Specification
–50 dBm ± 0.2 dB
± 1.5 dB
A-51
