Anritsu MS27200A Measurement Manual

Anritsu MS27200A Measurement Manual

Spectrum analyzer, remote spectrum monitor, spectrum monitor module
Hide thumbs

Advertisement

Quick Links

Download this manual
Measurement Guide
Spectrum Analyzer
MS2090A Field Master Pro™
MS2080A Field Master™
MS2070A Field Master™
MS27201A Remote Spectrum Monitor
MS27200A Spectrum Monitor Module
MS2089A Site Master™
Spectrum Analyzer
Wi-Fi Connectivity
Preamplifier
Tracking Generator
Interference Finder
Zero-Span IF Output
Gated Sweep
Coverage Mapping
IQ Capture/Streaming
Electromagnetic Field (EMF) Measurement
AM/FM Modulation Measurement
Not all instrument models offer every option or every measurement within a given option. Port
Note
terminologies may differ according to the instrument. Refer to the Technical Data Sheet of your
instrument for available options and supported measurements.
Anritsu Company
490 Jarvis Drive
Morgan Hill, CA 95037-2809
USA
Included
Option 5
Option 8
Option 20
Option 24
Option 89
Option 90
Option 431
Option 124/126 and 125/127
Option 444
Option 509
Part Number: 10580-00447
Revision: J
Published: March 2025
Copyright 2025 Anritsu Company

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS27200A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MS27200A

Summary of Contents for Anritsu MS27200A

  • Page 1 Measurement Guide Spectrum Analyzer MS2090A Field Master Pro™ MS2080A Field Master™ MS2070A Field Master™ MS27201A Remote Spectrum Monitor MS27200A Spectrum Monitor Module MS2089A Site Master™ Spectrum Analyzer Included Wi-Fi Connectivity Option 5 Preamplifier Option 8 Tracking Generator Option 20 Interference Finder...
  • Page 2 Anritsu Company. Export Management The Anritsu products identified herein and their respective manuals may require an Export License or approval by the government of the product country of origin for re-export from your country. Before you export these products or any of their manuals, please contact Anritsu Company to confirm whether or not these items are export-controlled.
  • Page 3 Contacting Anritsu for Sales and Service ........
  • Page 4 Table of Contents (Continued) Setting Amplitude Parameters ..........3-9 Setting Amplitude Units .
  • Page 5 Table of Contents (Continued) Setting Up Markers ............3-45 Placing a Normal Marker .
  • Page 6 Table of Contents (Continued) 3-18 Spectrum Emission Mask ........... . 3-92 Spectrum Emission Mask Measurement Basic Setup .
  • Page 7 Chapter 4—IA Spectrum Analyzer (Option 24) Introduction ..............4-1 Making IA Spectrum Analyzer Measurements .
  • Page 8 Contents-6 PN: 10580-00447 Rev. J Spectrum Analyzer MG...
  • Page 9 This measurement guide describes the SPECTRUM ANALYZER mode measurement functions of the Anritsu Field Master series, Site Master and Remote Spectrum Monitor instruments. Basic spectrum analyzer functions are included with all Anritsu spectrum analyzers. Advanced functions are available only when the related option is installed and activated. Refer to Section 1-2 “Option Descriptions”...
  • Page 10 1-2 Option Descriptions General Information Option Descriptions This section provides a brief overview of the available options covered in this guide. Not all instrument models offer every option. Some options are available as a time-limited trial. For example, Coverage Mapping option is offered as a 90-day time-limited option by ordering Option 9431.
  • Page 11 The actual displays, screen menus, and measurement details may differ based on the instrument, model, firmware version, installed options, and current instrument settings. Contacting Anritsu for Sales and Service To contact Anritsu, visit the following URL and select the services in your region: http://www.anritsu.com/contact-us. Spectrum Analyzer MG...
  • Page 12 1-4 Contacting Anritsu for Sales and Service General Information PN: 10580-00447 Rev. J Spectrum Analyzer MG...
  • Page 13 Spectrum Analyzer Overview 2-1 Introduction Chapter 2 — Spectrum Analyzer Overview Introduction This chapter provides an overview of the spectrum analyzer user interface and describes the main graphical displays and menus presented in the SPECTRUM ANALYZER mode of SPA application. Selecting the Applications/Modes The instrument applications are selected from the 9-dot icon or the current measurement icon.
  • Page 14 2-2 Selecting the Applications/Modes Spectrum Analyzer Overview RF Spectrum View RF Spectrum view is the default view and is suitable for viewing signals in the frequency domain where signal amplitude, bandwidth, and harmonic qualities can be studied. Select spectrum view from MEASURE > VIEW >...
  • Page 15 Spectrum Analyzer Overview 2-2 Selecting the Applications/Modes 1. Status Panel: Each measurement features a unique status panel that displays settings and information relevant to the current measurement and view settings. Refer to the “Status Panel” on page 2-6, for more information. 2.
  • Page 16 2-2 Selecting the Applications/Modes Spectrum Analyzer Overview Spectrogram View Spectrogram view is useful for identifying intermittent signals and for providing historical signal data in a comprehensive view. It provides a multi-dimensional “waterfall” display representing frequency, time, and amplitude. Frequency and time are shown on a typical two-dimensional scale while amplitude is displayed in the color dimension.
  • Page 17 Spectrum Analyzer Overview 2-3 Main Menu Main Menu The main menu is the primary access point for all instrument controls and measurement selections. The main function for each main menu button is described below. FREQ SPAN: Contains all frequency control settings such as center frequency, start and stop frequency, span, frequency offset, and frequency step.
  • Page 18 2-4 Status Panel Spectrum Analyzer Overview Status Panel Below is the spectrum analyzer status panel with the corresponding minimized status panel icons of RF spectrum measurement view. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 19 Spectrum Analyzer Measurements 3-1 Introduction Chapter 3 — Spectrum Analyzer Measurements Introduction The purpose of this chapter is to provide a starting point for making basic spectrum measurement setups. This chapter describes general instrument setup, including setting up frequency, bandwidth, amplitude, span, limit lines, and markers.
  • Page 20 3-3 Setting Frequency Parameters Spectrum Analyzer Measurements Setting Frequency Parameters Frequency-related parameters are set using the “FREQ / SPAN Menu” on page 3-6. The tuning frequency range can be entered in several different ways depending upon what makes the most sense, either for the user or for the measurement.
  • Page 21 Spectrum Analyzer Measurements 3-3 Setting Frequency Parameters Both positive and negative offset values are allowed. Negative offsets can be useful for seeing differences from expected values. Enter a negative offset of the expected value, and the received antenna frequency should display in the 0 Hz range.
  • Page 22 3-3 Setting Frequency Parameters Spectrum Analyzer Measurements Zero Span IF Output (Option 89) Zero Span IF output effectively allows the spectrum analyzer to be used as a receiver front-end, converting the input signal at the spectrum analyzer RF In connector to a signal centered at the IF output frequency. You can then process the IF signal in a way that meets your needs.
  • Page 23 Spectrum Analyzer Measurements 3-3 Setting Frequency Parameters The spectrum analyzer has several mixer bands. Depending on the operating frequency, the local oscillator may be above or below the input frequency. When the local oscillator frequency is below the input frequency, an increase in the input frequency results in an increase in the IF output frequency.
  • Page 24 3-3 Setting Frequency Parameters Spectrum Analyzer Measurements FREQ / SPAN Menu Access FREQ/SPAN menu from main menu. CENTER FREQUENCY: Sets the center frequency of the sweep range. The current span setting will remain constant or will be adjusted to accommodate the start and stop frequency range of the instrument.
  • Page 25 Spectrum Analyzer Measurements 3-3 Setting Frequency Parameters GESTURES Access Gestures submenu from main menu, FREQ/SPAN > GESTURES. DRAG: Toggles the touchscreen drag feature on or off. When toggled off, the center frequency will not change when dragging the spectrum display. This can be useful when dragging markers.
  • Page 26 3-3 Setting Frequency Parameters Spectrum Analyzer Measurements FREQ / SPAN Menu in Zero Span To access FREQ/SPAN (Zero Span) menu, from main menu press FREQ/SPAN > ZERO SPAN. CENTER FREQUENCY: Sets the center frequency of the sweep range. The current span setting will remain constant or will be adjusted to accommodate the start and stop frequency range of the instrument.
  • Page 27 Spectrum Analyzer Measurements 3-4 Setting Amplitude Parameters Setting Amplitude Parameters The amplitude scale corresponds to the y-axis display. The instrument supports both log units (such as dBm and dBV) and linear units of scale (such as volts or watts). Amplitude-related parameters are set using the “AMPLITUDE Menu”...
  • Page 28 3-4 Setting Amplitude Parameters Spectrum Analyzer Measurements Setting Amplitude Reference Level The amplitude reference level is typically an absolute reference level set at the top of the graticule for the power level being measured. Signal levels above this set value will be outside of the display range and may overdrive and saturate the input circuit (refer to “Indications of Excessive Signal Level”...
  • Page 29 Spectrum Analyzer Measurements 3-4 Setting Amplitude Parameters Preamplifier The preamplifier can be turned on and off by toggling PRE AMP via the status panel or the AMPLITUDE menu. Figure 3-5 shows the noise floor with the preamplifier off (1) and on (2). Note that when the preamplifier is turned on, the noise floor drops significantly and a low-level signal is exposed.
  • Page 30 3-4 Setting Amplitude Parameters Spectrum Analyzer Measurements Indications of Excessive Signal Level The instruments have built-in features to help prevent input overload. These include auto attenuation and reference level. The instrument will also indicate when a received signal is too high for the current setup by displaying an “ADC Overrange”...
  • Page 31 Spectrum Analyzer Measurements 3-4 Setting Amplitude Parameters AMPLITUDE Menu Access AMPLITUDE menu from main menu. REF LEVEL: The reference level is the top graticule line on the measurement display. If the reference level offset is not zero, the offset reference level is displayed at this location.
  • Page 32 IMPEDANCE: Select either 50 Ω, 75 Ω, or Other. Selecting 75 ohm selects the 7.5 dB loss of the Anritsu 12N50-75B adapter. For other adapters, select Other and enter the appropriate loss (0 dB is the default loss). Note that loss values are also applied to the relevant units.
  • Page 33 3-5 Field Strength Field Strength The field strength measurement is used in conjunction with an Anritsu antenna that has known antenna factors. Users can also import custom antenna factors for antennas not listed in the standard antenna selection list. When the field strength measurement is enabled, an additional plot is shown at the bottom of the display, indicating the selected antenna factor over the currently set frequency span.
  • Page 34 3-5 Field Strength Spectrum Analyzer Measurements 1. When the field strength measurement is enabled (2), all amplitude units are converted to display field strength in the selected units. 2. The field strength measurement and antenna is selected from the AMPLITUDE menu. 3.
  • Page 35 Spectrum Analyzer Measurements 3-5 Field Strength Example User Antenna Data To create a list of custom antenna factors, use the following steps: Export the existing USER ANTENNAS csv file by pressing the EXPORT button in the FIELD STRENGTH menu. From the FILES menu, move the exported file to a USB memory device and then to a computer for editing.
  • Page 36 3-5 Field Strength Spectrum Analyzer Measurements Antenna Calculations This section provides a list of various antenna calculations to convert from one unit of measure to another. Definitions P = power in watts V = voltage level in volts R = resistance in ohms –3 –6 Note that 1 mW = 10...
  • Page 37 Spectrum Analyzer Measurements 3-6 Setting Bandwidth Parameters Setting Bandwidth Parameters Bandwidth parameters are set using the “BANDWIDTH Menu” on page 3-21. Resolution Bandwidth Resolution Bandwidth (RBW) determines frequency selectivity. The spectrum analyzer traces the shape of the RBW filter as it tunes past a signal. The choice of resolution bandwidth depends on several factors. Filters take time to settle.
  • Page 38 3-6 Setting Bandwidth Parameters Spectrum Analyzer Measurements Setting Frequency Bandwidth Select BANDWIDTH on the main menu. Toggle AUTO RBW or AUTO VBW (or both) off to manually change values. If using Auto, refer to the following sections. Set the RBW and VBW to achieve the desired resolution and sweep characteristics. Lower values increase resolution and reduce noise, but at the expense of measurement (sweep) speed.
  • Page 39 Spectrum Analyzer Measurements 3-6 Setting Bandwidth Parameters BANDWIDTH Menu Access BANDWIDTH menu from main menu. AUTO RBW: When toggled on, the instrument selects the resolution bandwidth based on the current span width. The ratio of span width to RBW can be specified using the SPAN:RBW button.
  • Page 40 3-7 Setting Trace Parameters Spectrum Analyzer Measurements Setting Trace Parameters The instrument can display up to 6 traces simultaneously. Traces can be enabled from the TRACE menu by selecting the trace from the available selections, or you can select a trace in the Status panel to make it active. Each trace can have a separate trace type, mode, and detector.
  • Page 41 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters Trace Math in RF Spectrum View The figure below shows the instrument with trace 5 and 6 enabled on a signal, each with a different trace or detector type setting. The left side status panel shows a trace setup summary table. Touching one of the trace rows in the table will enable the trace and open the TRACE menu.
  • Page 42 3-7 Setting Trace Parameters Spectrum Analyzer Measurements Trace Normalization in RF Spectrum View The purpose of trace normalization is to bring the measured traces onto a common scale, allowing meaningful comparisons between different traces or measurements taken at different times or locations. By normalizing the traces, you can effectively remove the influence of factors such as different instrument sensitivities or attenuations, ensuring that the relative amplitudes of signals in the spectrum are accurately represented.
  • Page 43 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters TRACE Menu (Spectrum View) Access TRACE menu from main menu. SELECT: Selects traces 1 through 6. Selecting a trace that is off turns the trace on. The trace type will be Clear/Write, the trace mode will be Active, and the detector type will be Peak.
  • Page 44 3-7 Setting Trace Parameters Spectrum Analyzer Measurements DETECTOR TYPE: Selects one of the available detector types. Several detection methods tailor the function of the instrument to meet specific measurement requirements. There are often more measurement points across the screen than display points. The various detection methods are different ways of showing each display point (see “Trace Detector Types”...
  • Page 45 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters Trace Detector Types The figure below illustrates how the available detector types determine a trace data point from the sampled data. Peak Shows the maximum amplitude of sampled data for each display point, assuring that a narrow peak is not missed.
  • Page 46 3-7 Setting Trace Parameters Spectrum Analyzer Measurements Negative Shows the minimum amplitude of sampled data for each display point. This method is also useful when measuring modulated signals to see if some frequencies are not being used. Negative Detection Odd Display Point Sampling Interval Even Display Point Sampling Interval Odd Display Point Sampling Interval Frequency/Time Trace Data Point...
  • Page 47 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters Normal Shows random noise and signal data depending on the nature of the sampled data. If the signal both rises and falls during the sampling interval (random noise), then odd-numbered sampling intervals display the maximum value and even-numbered sampling intervals display the minimum value.
  • Page 48 3-7 Setting Trace Parameters Spectrum Analyzer Measurements Cursors in Spectrogram View The figure below shows the instrument with all six cursors enabled on a signal. Cursors are shown on the spectrogram as white lines. The active cursor is a solid white line and other cursors show as dashed white lines.
  • Page 49 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters TRACE Menu (Spectrogram View) When the combined Spectrogram view is selected (MEASURE > VIEW > Spectrogram), the TRACE and SETUP menus are updated with spectrogram and cursor setup controls. TYPE: Selects one of the following types of traces: •...
  • Page 50 3-7 Setting Trace Parameters Spectrum Analyzer Measurements PRESET DETECTORS: Presets the selected detector type. PRESET TRACES: Presets cursor and trace setup to Clear/Write, Active, with Peak Detector. CURSOR: Opens the “TRACE CURSOR Menu” on page 3-32. RECORD: Opens the “TRACE RECORD Menu” on page 3-36.
  • Page 51 (Not by “sweeping” through all the trace points). Recordings can be initiated on both the instrument or from the Anritsu Remote and Report Tool (ARRT) when connected to an instrument. The files are saved as .fmrec on the instrument internal memory and must be played back on the instrument.
  • Page 52 3-7 Setting Trace Parameters Spectrum Analyzer Measurements 1. Recorded trace and spectrum waterfall. 8. Starts playback of the selected trace recording. During playback, the button changes to the PAUSE 2. Shows either the recording, playback and CSV button, allowing pausing of the playback. logging pause indicator.
  • Page 53 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters CSV Logging CSV logging provides much of the same functionality as trace recording described above, but a CSV log cannot be replayed. CSV logging allows continuous recording of either live trace data or playback trace data to a CSV file with frequency and amplitude information for all traces captured during the logging period.
  • Page 54 3-7 Setting Trace Parameters Spectrum Analyzer Measurements TRACE RECORD Menu The trace recording feature is accessed via the TRACE > RECORD menus. This feature allows you to record a trace for future playback on the instrument or ARRT RECORD: Starts a trace recording session and saves traces and setup data to a record file (.fmrec).
  • Page 55 Spectrum Analyzer Measurements 3-7 Setting Trace Parameters TRACE PLAYBACK Menu The trace playback feature is accessed via the TRACE > PLAYBACK menus. This feature allows you to play back a recorded trace (.fmrec) file on the instrument or ARRT. A playback session must be started by first recalling a previously recorded session. RECALL: Opens the file manager so you can select a recorded trace file for playback.
  • Page 56 3-7 Setting Trace Parameters Spectrum Analyzer Measurements TRACE CSV LOGGING Menu The trace CSV capture feature is accessed via the TRACE > CSV CAPTURE menus. This feature allows you to capture trace data in comma separated value (.csv) format. RECORD: Starts a recording session and saves trace and setup data to a CSV file (.csv).
  • Page 57 “smeared” look to it, with the spectral lines being wider than normal and shifted to the right and at a lower amplitude than is correct. Anritsu Field Master Series is designed to relieve the user from having to calculate the sweep speed or experiment to discover a sweep speed that yields accurate results. When changing the RBW and VBW, the sweep speed automatically changes to the fastest sweep speed that will yield accurate results.
  • Page 58 3-8 Setting Sweep Parameters Spectrum Analyzer Measurements SWEEP Menu Access SWEEP menu from main menu. CONTINUOUS: Toggles between continuous sweep and single sweep. When the toggle is off, the instrument is in single sweep. In single sweep, the results of a sweep are displayed on the screen while the instrument awaits a trigger event to start a new sweep.
  • Page 59 Spectrum Analyzer Measurements 3-8 Setting Sweep Parameters Gated Sweep (Option 90) Gated sweep is only available on instruments with Option 90 installed. Gated sweep allows you to synchronize your sweep with an event so that the analyzer collects data at the appropriate time. This is useful for measuring signals in the time domain such as pulsed RF, time multiplexed, or burst modulated signals.
  • Page 60 3-8 Setting Sweep Parameters Spectrum Analyzer Measurements GATED SWEEP Access GATED SWEEP submenu from SWEEP > GATED SWEEP. GATED SWEEP: Toggles gated sweep on or off. GATED SOURCE: Selects the trigger source for the gated sweep. • GNSS (GPS): This setting synchronizes the trigger source to the GPS PPS. •...
  • Page 61 Spectrum Analyzer Measurements 3-8 Setting Sweep Parameters POWER VS TIME Display When power vs time is enabled, a time-domain graph is presented. This graph is a useful visual aid when setting up the GATE DELAY (1) and GATE LENGTH (2) times as you can simultaneously view the signal level within the set frame and relative to your gate delay and length.
  • Page 62 3-8 Setting Sweep Parameters Spectrum Analyzer Measurements GATED SWEEP ON Display When gated sweep toggle in turned ON, a time-domain graph is displayed on the bottom and frequency domain graph is shown on top of it, as shown in Figure 3-32.
  • Page 63 Spectrum Analyzer Measurements 3-9 Setting Up Markers Setting Up Markers Marker parameters are set using the “MARKER Menu” on page 3-47. Refer to the figure below when working with this section. 1. RF Spectrum view marker information display. 2. Marker located on trace. The active marker is indicated with solid green fill, other markers will show with a hollow fill, fixed markers show as a green X.
  • Page 64 3-9 Setting Up Markers Spectrum Analyzer Measurements Placing a Normal Marker Select MARKER to display markers. If markers were off, Marker 1 will automatically be made active at the current center frequency. Select another marker using MARKER > SELECT, then select one of 12 available markers. If the marker was off, the marker will be made active and placed at the center frequency.
  • Page 65 Spectrum Analyzer Measurements 3-9 Setting Up Markers MARKER Menu Access MARKER menu from main menu. PEAK SEARCH: Opens the “MARKER PEAK SEARCH” on page 3-49. SELECT: Turns on the selected marker if it is off or makes it the active marker if it is already turned on.
  • Page 66 3-9 Setting Up Markers Spectrum Analyzer Measurements DELTA REFERENCE: Selects the Reference marker for a Delta marker. A Delta marker cannot be its own reference. Only Fixed and Normal markers may be used as a reference for Delta markers. TRACE: Selects the trace number to which the marker is currently attached. MARKER TABLE: Toggle on or off the marker table displayed below the screen.
  • Page 67 Spectrum Analyzer Measurements 3-9 Setting Up Markers MARKER PEAK SEARCH Access PEAK SEARCH submenu from MARKER menu. Note Double tapping a marker opens a quick peak search menu with some of the below features. PEAK SEARCH: Returns to the main MARKER menu. SELECT: If the selected marker is off, it will be turned on and the selected marker positioned at the peak of Trace 1.
  • Page 68 3-9 Setting Up Markers Spectrum Analyzer Measurements Marker Functions Noise Markers Noise Markers use an averaging routine applied to multiple data-point groups to calculate the readout, which is typically comparable to using 1 Hz bandwidth filtering. Because the noise marker routine uses groups of data points for the calculation, the noise marker should not be placed in close proximity to measurable signals.
  • Page 69 Spectrum Analyzer Measurements 3-9 Setting Up Markers Spectrogram with Cursors and Markers In the spectrum window, markers are shown as hollow green diamonds on the trace to which they are assigned. Active markers have a solid fill with a vertical dashed line that can be used to drag the marker position.
  • Page 70 3-9 Setting Up Markers Spectrum Analyzer Measurements Marker Table The marker table display is useful for displaying many marker parameters at once. The examples shown are for the regular Spectrum view (1) and for Spectrogram view (2). Both marker tables show the marker mode and corresponding X and Y values.
  • Page 71 Spectrum Analyzer Measurements 3-10 Setting Up Limit Lines 3-10 Setting Up Limit Lines Limit lines allow you to monitor when trace data crosses a defined line. Two types of limit lines can be specified: lower limit lines and upper limit lines. Limit lines can be used for visual reference, pass/fail criteria, and to trigger a save on event.
  • Page 72 3-10 Setting Up Limit Lines Spectrum Analyzer Measurements Limit Line Envelope Limit line envelope parameters are set using the “LIMIT ENVELOPE Menu” on page 3-58. The limit line envelope feature is a quick way to generate an envelope using the existing trace as a reference. You can set the envelope to square or slope and you can set the limit line offset from the trace when creating the envelope.
  • Page 73 Spectrum Analyzer Measurements 3-10 Setting Up Limit Lines LIMIT Menu Access LIMIT menu from main menu. SELECT: Selects UPPER or LOWER limit line for editing. ENABLED: Displays the selected limit when toggled on. ALARM: This setting is for toggling the alarm function on or off for the currently active limit line.
  • Page 74 3-10 Setting Up Limit Lines Spectrum Analyzer Measurements LIMIT EDIT Access EDIT submenu from LIMIT menu. SELECTED POINT: Displays the limit line point number. Select to select a different point from the displayed list. FREQUENCY: Sets the frequency of a limit line inflection point. The frequency of each point in a limit line can be individually set.
  • Page 75 Spectrum Analyzer Measurements 3-10 Setting Up Limit Lines LIMIT MOVE Menu Access MOVE submenu from LIMIT menu. CENTER: Selecting this button moves the center of the existing limit line to the center frequency of the measurement. The span of the existing limit line is not changed. Use this button as an easy way to move an existing limit line to the center of the sweep.
  • Page 76 3-10 Setting Up Limit Lines Spectrum Analyzer Measurements LIMIT ENVELOPE Menu Access ENVELOPE submenu from LIMIT menu. SELECT: Select this button to select UPPER or LOWER for envelope design. ENVELOPE POINTS: This sets the desired number of envelope points. AMPLITUDE OFFSET: Use to define how far away from the trace to place the upper or lower envelope.
  • Page 77 Spectrum Analyzer Measurements 3-11 Setting Up Triggering 3-11 Setting Up Triggering The TRIGGER menu is not available in regular swept frequency spectrum measurements. Trigger parameters for zero span are set using the “TRIGGER Menu in Zero Span” on page 3-59. IQ Trigger (Option 124/126) is set using the “IQ TRIGGER”...
  • Page 78 3-11 Setting Up Triggering Spectrum Analyzer Measurements Positive Edge Trigger High Threshold Hysteresis Level Not Triggered Low Threshold Negative Edge Trigger Figure 3-45. Trigger Levels and Hysteresis 3-60 PN: 10580-00447 Rev. J Spectrum Analyzer MG...
  • Page 79 Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements 3-12 Setting Up Advanced Measurements Refer to Section 3-3 Section 3-11 for basic information on setting up a spectrum measurement. This section provides setup information for making swept spectrum measurements. The instrument features smart measurements that make setup easy.
  • Page 80 3-12 Setting Up Advanced Measurements Spectrum Analyzer Measurements VIEW: Selects the desired measurement view from the following list: • RF Spectrum: RF Spectrum View • Spectrogram: When Spectrogram view is selected, a Spectrogram view is added to the display. Spectrogram is only available when the MEASUREMENT is set to Spectrum.
  • Page 81 Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements Burst Average Power Burst Average Power is the average power measured between two user defined markers positioned in the time domain.. 1. Status Panel: The status panel provides quick access to common spectrum analyzer settings. 2.
  • Page 82 3-12 Setting Up Advanced Measurements Spectrum Analyzer Measurements IQ CAPTURE (Option 124/126) To access IQ CAPTURE submenu go to MEASURE from main menu. Note that IQ capture submenu is only available in instruments installed with options 124/126. START/STOP CAPTURE: Touch this button to execute an IQ capture. When a capture is initiated, this button changes to STOP CAPTURE and can be touched to stop the continuous captures.
  • Page 83 Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements SAVE CAPTURE: Saves captured data to a file when SAVE TO FILE is set to Manual. FILE NAME PREFIX: Sets the file name prefix of the capture file. Files are stored a “Captures”...
  • Page 84 3-12 Setting Up Advanced Measurements Spectrum Analyzer Measurements IQ STREAMING (Option 125/127) To access IQ streaming submenu, go to main menu MEASURE > IQ CAPTURE > CAPTURE MODE > Streaming. START STREAM: Touch this button to start IQ data streaming from the selected output port.
  • Page 85 Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements DATA OUTPUT FORMAT: Selects the data out format of IQC or PCIe. IQC is the default format and is intended for use with the MA25424A IQ Data Converter (Refer to the IQ Capture/Streaming Measurement Guide, PN: 10580-00490).
  • Page 86 3-12 Setting Up Advanced Measurements Spectrum Analyzer Measurements IQ TRIGGER Access IQ TRIGGER submenu from TRIGGER from MEASURE > IQ CAPTURE. Trigger commands are shared between IQ capture and zero span, so these two functions are Note mutually exclusive. TIMESTAMPS: toggles data collection timestamps on or off (Refer to the IQ Capture/Streaming Measurement Guide, PN: 10580-00490).
  • Page 87 Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements Positive Edge Trigger High Threshold Hysteresis Level Not Triggered Low Threshold Negative Edge Trigger Figure 3-54. Trigger Levels and Hysteresis IQ Streaming Tool The IQ STREAMING menu allows you to concatenate an existing IQ metadata file (.dgzm) with a session of IQ data files (.dgz) that were streamed to a USB device after the stream operation is complete.
  • Page 88 3-13 Transmission (Option 20) Spectrum Analyzer Measurements 3-13 Transmission (Option 20) To select transmission measurement go to main menu and press MEASURE > MEASUREMENT >Transmission. Transmission measurement is only available if tracking generator Option 20 is installed. Transmission measurement includes a tracking generator that generates a swept signal with an output frequency that is the same as the tuning frequency of the spectrum analyzer, and a continuous wave (CW) generator that allows the user to set sine wave output frequency and power.
  • Page 89 Spectrum Analyzer Measurements 3-13 Transmission (Option 20) STATUS PANEL (Transmission) Below is the status panel with the corresponding minimized status panel icons for Transmission measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 90 3-13 Transmission (Option 20) Spectrum Analyzer Measurements SETUP Menu (Transmission) To access the SETUP menu select MEASURE > MEASUREMENT > Transmission > SETUP, or press SETUP menu from the main menu. The setup menu consists of GENERATOR submenu. GENERATOR: Opens the “GENERATOR Menu (Option 20)”...
  • Page 91 Spectrum Analyzer Measurements 3-13 Transmission (Option 20) Tracking Generator Overview Turning the Tracking Generator on sets the sweep mode to No FFT. Turning off the generator Note presets the parameters to their previous settings. Either parameter may be changed by the user with the Tracking Generator on or by the instrument when other measurements are also turned on.
  • Page 92 3-13 Transmission (Option 20) Spectrum Analyzer Measurements Figure 3-60. Connection of Bandpass Filter as DUT - Transmission Measurement Mixer Testing In this example the input to the mixer Local Oscillator (LO) is 200 MHz and the RF input range is 4.8 GHz to 5.8 GHz.
  • Page 93 Spectrum Analyzer Measurements 3-13 Transmission (Option 20) Figure 3-61. Connection of Mixer as DUT - Transmission Measurement Spectrum Analyzer MG PN: 10580-00447 Rev. J 3-75...
  • Page 94 3-13 Transmission (Option 20) Spectrum Analyzer Measurements CW Generator Overview The Tracking Generator Option 20 also includes a continuous wave (CW) generator. The CW Signal Generator provides a continuous wave signal from the GENERATOR/RF OUT port of the instrument. The CW generator consists of two modes CW Fixed and CW Coupled.
  • Page 95 Spectrum Analyzer Measurements 3-13 Transmission (Option 20) 8. Set the generator mode to CW Coupled from MODE submenu. 9. When CW Coupled mode is selected, the tracking generator frequency is always tuned to the center frequency of the spectrum analyzer. In this case the CENTER FREQUENCY is set to 909 MHz and so that is the freq of the signal source.
  • Page 96 3-14 Total Harmonic Distortion (THD) Spectrum Analyzer Measurements 3-14 Total Harmonic Distortion (THD) To access THD measurement go to main menu and press MEASURE > MEASUREMENT >THD. The THD result is calculated from the relative values of the 2nd, 3rd, 4th, 5th, 6th and 7th harmonics to the fundamental (carrier) frequency.
  • Page 97 Spectrum Analyzer Measurements 3-14 Total Harmonic Distortion (THD) STATUS PANEL (THD) Below is the status panel with the corresponding minimized status panel icons for THD measurement. From main menu, select MEASURE > MEASUREMENT > THD. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 98 3-14 Total Harmonic Distortion (THD) Spectrum Analyzer Measurements SETUP Menu (THD) The THD SETUP menu is available in MEASURE > MEASUREMENT > THD. AUTO FUND FREQ: Sets fundamental frequency automatically, when turned on. Turn it off to manually enter the value of FUNDAMENTAL FREQ. FUNDAMENTAL FREQ: Sets the fundamental frequency manually.
  • Page 99 Spectrum Analyzer Measurements 3-15 Channel Power 3-15 Channel Power To select channel power measurement go to main menu and press MEASURE > MEASUREMENT >Channel Power. The channel power measurements are set up using the “SETUP Menu (Channel Power)” on page 3-83.
  • Page 100 3-15 Channel Power Spectrum Analyzer Measurements STATUS PANEL (Channel Power) Below is the status panel with the corresponding minimized status panel icons for channel power measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 101 Spectrum Analyzer Measurements 3-15 Channel Power SETUP Menu (Channel Power) The channel power SETUP menu is available in MEASURE > MEASUREMENT > Channel Power > SETUP. Once the channel power measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 102 3-16 Occupied Bandwidth Spectrum Analyzer Measurements 3-16 Occupied Bandwidth To select OBW measurement go to main menu and press MEASURE > MEASUREMENT >OBW. Occupied bandwidth measurements are set up using the “SETUP Menu (Occupied BW)” on page 3-87. Occupied Bandwidth (OBW) is a common measurement performed on radio transmitters. This measurement calculates the bandwidth containing the total integrated power occupied in a given signal bandwidth.
  • Page 103 Spectrum Analyzer Measurements 3-16 Occupied Bandwidth • Select the METHOD (Percent (%) or dBc (X DB) • Toggle OBW limit testing if you wish to see pass/fail test results Occupied bandwidth is a constant measurement; after it is turned on, it remains on until a different measurement is selected or the sweep is paused.
  • Page 104 3-16 Occupied Bandwidth Spectrum Analyzer Measurements STATUS PANEL (Occupied BW) Below is the status panel with the corresponding minimized status panel icons for occupied bandwidth measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 105 Spectrum Analyzer Measurements 3-16 Occupied Bandwidth SETUP Menu (Occupied BW) The occupied bandwidth SETUP menu is available in MEASURE > MEASUREMENT > OBW > SETUP. Once the OBW measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum display.
  • Page 106 3-17 Adjacent Channel Power Spectrum Analyzer Measurements 3-17 Adjacent Channel Power To select Adjacent Channel Power (ACP) measurement go to main menu and press MEASURE > MEASUREMENT >ACP. ACP is a measure of the power that leaks into adjacent transmit channels. The ACP measurement measures the power present in the transmit channel (refer to “Channel Power”...
  • Page 107 Spectrum Analyzer Measurements 3-17 Adjacent Channel Power Adjacent channel power is a constant measurement; after it is turned on, it remains on until a different measurement is selected or the sweep is paused. ACP is calculated at the end of each sweep. Spectrum Analyzer MG PN: 10580-00447 Rev.
  • Page 108 3-17 Adjacent Channel Power Spectrum Analyzer Measurements STATUS PANEL (ACP) Below is the status panel with the corresponding minimized status panel icons for adjacent channel power measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 109 Spectrum Analyzer Measurements 3-17 Adjacent Channel Power SETUP Menu (ACP) The Adjacent Channel Power SETUP menu is available in MEASURE > MEASUREMENT > ACP > SETUP. Once the ACP measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 110 3-18 Spectrum Emission Mask Spectrum Analyzer Measurements 3-18 Spectrum Emission Mask To select spectral emission mask measurement go to main and menu press MEASURE > MEASUREMENT >SEM. The SEM measurement parameters are set up using the “SETUP Menu (SEM)” on page 3-95.
  • Page 111 Spectrum Analyzer Measurements 3-18 Spectrum Emission Mask 1. The status panel provides quick access to common spectrum analyzer settings. See “STATUS PANEL (SEM)” on page 3-94. 2. SEM Mask 3. Spectrum Emission 4. SEM Mask 5. All SEM measurement parameters are set via the SETUP menu. See “SETUP Menu (SEM)”...
  • Page 112 3-18 Spectrum Emission Mask Spectrum Analyzer Measurements STATUS PANEL (SEM) Below is the status panel with the corresponding minimized status panel icons that is unique only to spectral emission mask measurement. AUTO MAX PWR: Toggle auto maximum power to set the maximum power automatically.
  • Page 113 Spectrum Analyzer Measurements 3-18 Spectrum Emission Mask SETUP Menu (SEM) SELECT MASK: Selects the desired upper or lower emission mask. Choose the desired mask from the list. IMPORT MASK: Used to import a custom user mask. EXPORT MASK: Exports an example user mask as a comma separated value file (see “Example Custom Signal Emission Mask”...
  • Page 114 3-19 PIM/Interference (Option 24) Spectrum Analyzer Measurements 3-19 PIM/Interference (Option 24) To select PIM/Interference measurement go to main menu and press MEASURE > MEASUREMENT >PIM/Interference. The PIM/interference measurement is set up using the “SETUP Menu (PIM/Interference)” on page 3-99. The interference finder measurement is used in conjunction with a directional antenna to locate the direction of an interfering signal.
  • Page 115 Spectrum Analyzer Measurements 3-19 PIM/Interference (Option 24) • Set the MAX LEVEL and MIN LEVEL for the audio pitch response of the measurement. Note that these settings can also be dragged into position using the indicator bars in the display panel. •...
  • Page 116 3-19 PIM/Interference (Option 24) Spectrum Analyzer Measurements STATUS PANEL (PIM/Interference) Below is the status panel with the corresponding minimized status panel icons for interference measurement. VOLUME: Sets the volume level for the audio response of the measurement. Note that the system volume can affect the range of this setting. REF LEVEL: Sets the reference level of the top graticule line in the selected units.
  • Page 117 Spectrum Analyzer Measurements 3-19 PIM/Interference (Option 24) SETUP Menu (PIM/Interference) The interference finder SETUP menu is available in MEASURE > MEASUREMENT > PIM/Interference > SETUP. Once the interference measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 118 Electromagnetic Field (EMF) measurement functions available with Option 444. Option 444 must be used in conjunction with an Anritsu isotropic antenna at a frequency range that is within specification of the instrument and antenna used. Refer to your technical data sheet for compatible antennas.
  • Page 119 Spectrum Analyzer Measurements 3-20 Electromagnetic Field (EMF) Measurements (Option 444) The instrument is now ready to set up and start an EMF measurement. Figure 3-82. Isotropic Antenna Connection Spectrum Analyzer MG PN: 10580-00447 Rev. J 3-101...
  • Page 120 3-20 Electromagnetic Field (EMF) Measurements (Option 444) Spectrum Analyzer Measurements After completing the data collection for the three axes (X, Y, and Z), the isotropic result is calculated and displayed. In addition to the traces displayed on the user interface (axis sweep data, current isotropic result, and average and max isotropic result), the max, min, and average of the total integrated power of the isotropic result over time is computed and displayed in the table below the graph region.
  • Page 121 Spectrum Analyzer Measurements 3-20 Electromagnetic Field (EMF) Measurements (Option 444) STATUS PANEL (EMF Measurement) Below is the status panel with the corresponding minimized status panel icons for EMF measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 122 3-20 Electromagnetic Field (EMF) Measurements (Option 444) Spectrum Analyzer Measurements SETUP Menu (EMF) The EMF measurement SETUP menu is available in MEASURE > MEASUREMENT > EMF Measurement > SETUP. Once the EMF measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 123 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) 3-21 Coverage Mapping (Option 431) To select coverage mapping go to main menu and press MEASURE > MEASUREMENT >Coverage Mapping. The coverage mapping measurement is set up using the “SETUP Menu (Coverage Mapping)” on page 3-111.
  • Page 124 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements Outdoor Coverage Mapping With a valid GNSS (GPS) signal, the instrument identifies the current location on the displayed map with a location pin. As the location changes during a measurement, colored-coded dots corresponding to the received signal strength/power are placed at distance or time intervals.
  • Page 125 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) 1. The coverage mapping status panel provides quick access to common settings and allows you to start and stop a coverage mapping measurement. A color-coded signal strength legend including the corresponding percentage values are also displayed. See “STATUS PANEL (Coverage Mapping)”...
  • Page 126 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements Indoor Coverage Mapping Indoor coverage mapping does not use a GNSS (GPS) signal to identify the current location, but rather relies on the user to touch the location pin to where they are located on a building floor plan, or map, that is shown on the instrument display.
  • Page 127 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) MEASUREMENT Menu (Coverage Mapping) The coverage mapping measurement SETUP menu is available in MEASURE > MEASUREMENT > Coverage Mapping > SETUP. Once the coverage mapping measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 128 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements STATUS PANEL (Coverage Mapping) The status panel illustrated in Figure 3-89 is unique to the coverage mapping measurement. START MEAS: Initiates a coverage mapping measurement. A valid GPS antenna must be connected to the instrument and enabled for a measurement data to be recorded.
  • Page 129 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) SETUP Menu (Coverage Mapping) The coverage mapping SETUP menu is available in MEASURE > MEASUREMENT > Coverage Mapping > SETUP. Once coverage mapping is selected, start the mapping measurement via MEASURE > START MEAS. Once the coverage mapping measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 130 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements COLOR SETUP Menu (Coverage Mapping) The coverage mapping measurement COLOR SETUP menu is available in MEASURE > MEASUREMENT > Coverage Mapping > SETUP > COLOR SETUP. Once the coverage mapping measurement is selected, the SETUP menu can be quickly accessed by tapping on the summary display area below the spectrum window.
  • Page 131 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) Map Tool The Map tool includes an embedded, low detail world base map. The MAP TOOL provides access to downloadable, high detail map tiles for offline use during signal mapping. The map tiles that you download have the same detail that is accessible through an active Internet connection.
  • Page 132 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements 1. The map zoom tool is used to increase (+) or decrease (-) zoom level. You can also drag the zoom level indicator up or down, or you can pinch to change zoom level. 2.
  • Page 133 Spectrum Analyzer Measurements 3-21 Coverage Mapping (Option 431) Downloading and Importing/Uploading Map Tiles Touch and drag the map to the desired area, then use the zoom tools in the upper left to show an area that is centered and is a little larger than the area that you wish to conduct your signal mapping measurements.
  • Page 134 3-21 Coverage Mapping (Option 431) Spectrum Analyzer Measurements If you are using the ARRT, click upload icon from the list of available maps to upload the specific map tiles to the instrument. You will see a dialog to enter the instrument IP address for the upload. If not automatically detected, enter the instrument IP address, then touch the upload icon.
  • Page 135 Spectrum Analyzer Measurements 3-22 AM/FM Audio (Requires Option 24 or Option 509) 3-22 AM/FM Audio (Requires Option 24 or Option 509) To select AM/FM Audio measurement go to main menu and press MEASURE > MEASUREMENT > AM/FM Audio. To select RF Spectrum view go to MEASURE > VIEW> RF Spectrum. The AM/FM audio measurement is set up using the “SETUP Menu (AM/FM Audio RF Spectrum)”...
  • Page 136 3-22 AM/FM Audio (Requires Option 24 or Option 509) Spectrum Analyzer Measurements AM/FM Audio – RF Spectrum View The RF spectrum view displays the carrier signal power of the demodulated AM/FM audio signal in frequency domain.Toggle DEMOD MARKER button to identify the peak value of the carrier power. You can also record the audio signal by setting the duration time.
  • Page 137 Spectrum Analyzer Measurements 3-22 AM/FM Audio (Requires Option 24 or Option 509) SETUP Menu (AM/FM Audio RF Spectrum) The default view of AM/FM Audio measurement is RF spectrum view. The AM/FM audio demodulation SETUP menu is available in MEASURE > MEASUREMENT > AM/FM Audio > SETUP. DEMOD FREQ: Sets the audio demodulation frequency.
  • Page 138 3-23 AM/FM Modulation Measurement (Option 509) Spectrum Analyzer Measurements 3-23 AM/FM Modulation Measurement (Option 509) To select AM/FM modulation measurements view go to main menu and press MEASURE > MEASUREMENT > AM/FM Audio, and select ALL MEASUREMENTS from the VIEW drop-down. The AM/FM modulation measurements are set up using the “SETUP Menu (AM/FM Audio –...
  • Page 139 Spectrum Analyzer Measurements 3-23 AM/FM Modulation Measurement (Option 509) 1. The status panel provides quick access to common spectrum analyzer settings. See “STATUS PANEL (AM/FM Audio)” on page 3-125. 2. The audio spectrum displays the frequency spectrum of the demodulated audio signal. It displays depth (%) in amplitude modulation, and deviation (Hz) in frequency modulation.
  • Page 140 3-23 AM/FM Modulation Measurement (Option 509) Spectrum Analyzer Measurements AM/FM Metrics Field Master Series and Remote Spectrum Monitor instruments automatically detect the highest power audio tone which is used as the fundamental tone for the audio signal in Signal-to-noise and distortion (SINAD) measurement, therefore it is not required to define the frequency of the fundamental tone.
  • Page 141 Spectrum Analyzer Measurements 3-23 AM/FM Modulation Measurement (Option 509) Total harmonic distortion (THD) measurement extracts the total harmonic distortion component from the noise component in the total unwanted signal. The isolated distortion component is useful to troubleshoot the root causes of the modulation distortion. ...
  • Page 142 3-23 AM/FM Modulation Measurement (Option 509) Spectrum Analyzer Measurements SETUP Menu (AM/FM Audio – All Measurements View) The AM/FM audio demodulation SETUP menu is available in MEASURE > MEASUREMENT > AM/FM Audio > SETUP. DEMOD FREQ: Sets the audio demodulation frequency. DEMOD MKR: Toggles the tracked marker on and sets the demod frequency to track the marker frequency.
  • Page 143 Spectrum Analyzer Measurements 3-23 AM/FM Modulation Measurement (Option 509) STATUS PANEL (AM/FM Audio) Below is the status panel with the corresponding minimized status panel icons for AM/FM audio measurement. The status panel holds good for Option 24 and Option 509. REF LEVEL: Sets the reference level of the top graticule line in the selected units.
  • Page 144 3-24 Carrier-to-Interference Spectrum Analyzer Measurements 3-24 Carrier-to-Interference To select carrier-to-interference (C/I) measurement go to main menu and press MEASURE > MEASUREMENT >C/I measurement. The C/I measurement is set up using the “SETUP Menu (C/I)” on page 3-130.Carrier-to-interference (C/I) measurement is the ratio of the total RF power in the defined integration bandwidth, including transmitter power, noise, interference and distortion, to the power in the channel when the transmitter is turned off.
  • Page 145 Spectrum Analyzer Measurements 3-24 Carrier-to-Interference 1. Status panel provides quick access to all the spectrum analyzer menu settings. See “STATUS PANEL (C/I)” on page 3-129. 2. The C/I table shows the carrier-to-interference ratio (dB), carrier power and interference power measured in dBm.The Pass/Fail status is populated only if the limits are toggled on in LIMITS menu.
  • Page 146 3-24 Carrier-to-Interference Spectrum Analyzer Measurements The power in the interference part of the measurement can result from different sources: • Adjacent Channel Power overlapping into the wanted channel Frequency Trace Noise Figure 3-103.Adjacent Interference • Broadband Noise Broadband Interference Broadband Interference Noise Analyzer noise floor Noise Frequency Noise...
  • Page 147 Spectrum Analyzer Measurements 3-24 Carrier-to-Interference STATUS PANEL (C/I) Below is the status panel with the corresponding minimized status panel icons for C/I measurement. REF LEVEL: Sets the reference level of the top graticule line in the selected units. If the reference level offset is not zero, OFFSET REF LEVEL is displayed at this location.
  • Page 148 3-24 Carrier-to-Interference Spectrum Analyzer Measurements SETUP Menu (C/I) The C/I SETUP menu is available in MEASURE > MEASUREMENT > C/I > SETUP. CENTER FREQUENCY: Sets the center frequency of the sweep range. SPAN: Sets the sweep frequency range. Selecting the plus (+) or minus (–) control increments the span value in a 1:2:5 sequence.
  • Page 149 Spectrum Analyzer Measurements 3-24 Carrier-to-Interference LIMITS Menu C/I LIMIT: Sets the carrier-to-interference ratio limit in dB. Enter the desired C/I ratio (dB) limit value using the numeric keypad. POWER LIMIT: Sets the desired value of the carrier power limit. Enter the desired carrier power (dBm) limit value using the numeric keypad.
  • Page 150 3-25 SETUP Menu Spectrum Analyzer Measurements 3-25 SETUP Menu There are no advanced measurement setups for the basic spectrum analyzer measurement. Figure 3-109. SETUP Menu (RF Spectrum) Refer to the sections below for additional setup menus when using advanced measurements: •...
  • Page 151 Spectrum Analyzer Measurements 3-26 Presetting the Analyzer 3-26 Presetting the Analyzer The PRESET menu sets certain settings to the default state. Preset only affects the current analyzer settings, such as those for the spectrum analyzer or for the 5GNR analyzer. Preset does not affect user files or system settings such as networking settings.
  • Page 152 3-27 Saving and Recalling Measurements Spectrum Analyzer Measurements 3-27 Saving and Recalling Measurements The instrument can save measurement setups, native trace and CSV trace data, limit line setups, and screenshots. You can recall setup, native trace, and limit line files. For other file operations such as copy, move, and directory management, refer to the product’s user guide for more information on file management.
  • Page 153 Spectrum Analyzer Measurements 3-27 Saving and Recalling Measurements Recalling a Measurement You can recall a saved setup, native trace measurement, and a limit line. When recalling a setup, the instrument setup and operating state will be restored as it was when the setup was saved. When recalling a trace measurement, the instrument setup and on-screen measurement data will be restored as it was when the trace data was saved.
  • Page 154 3-27 Saving and Recalling Measurements Spectrum Analyzer Measurements FILE Menu Access FILE menu from main menu. QUICK SAVE: saves a setup file immediately with the name shown in the button. The number in the name is incremented automatically so that the new name is ready for the next setup file to be saved.
  • Page 155 Spectrum Analyzer Measurements 3-27 Saving and Recalling Measurements SAVE ON EVENT To access SAVE ON EVENT submenu go to FILE menu. Save on event saves the current trace data to a folder named with the current date and time (yyyymmddhhmmss). LIMIT CROSSED: When enabled, measurement trace data is automatically saved when the trace crosses a limit line that has been specified in the LIMIT menu.
  • Page 156 3-27 Saving and Recalling Measurements Spectrum Analyzer Measurements 3-138 PN: 10580-00447 Rev. J Spectrum Analyzer MG...
  • Page 157 Chapter 4 — IA Spectrum Analyzer (Option 24) Introduction ™ The Interference Analyzer (IA) spectrum and MA2700A handheld InterferenceHunter are the ideal solution for anyone conducting coverage testing of RF and microwave communications systems, including 5G and LTE networks. The Interference Analyzer (IA) SPECTRUM mode of SPA application assists you in finding the source of interfering signals with the use of MA2700A handheld InterferenceHunter, GPS receiver, and directional antenna.
  • Page 158 4-2 Making IA Spectrum Analyzer Measurements IA Spectrum Analyzer (Option 24) Making IA Spectrum Analyzer Measurements Initial Setup • Connect a signal source to the RF In port of the instrument. For over-the-air measurements, connect an antenna that is appropriate for the frequency range to be measured. For connector descriptions, refer to Connector Panel section of the product’s user guide.
  • Page 159 IA Spectrum Analyzer (Option 24) 4-3 Setting Up Advanced Measurements Setting Up Advanced Measurements Refer to “Making IA Spectrum Analyzer Measurements” on page 4-2 for basic information on setting up a IA spectrum measurement. This section provides setup information for making swept spectrum measurements. The Field Master Series analyzer features smart measurements that make setup easy.
  • Page 160 4-4 Interference Map IA Spectrum Analyzer (Option 24) Interference Map This section describes the Interference Map capability and key characteristics of Interference Map measurement mode. This technique is used to geo-locate interfering signals with respect to the user’s current location. The user is required to travel with the instrument connected with a GPS receiver, directional antenna and the MA2700A InterferenceHunter to more than one location to capture the triangulation of the interfering signals.
  • Page 161 IA Spectrum Analyzer (Option 24) 4-4 Interference Map 1. The map zoom tool is used to increase (+) or decrease (-) zoom level. You can also drag the zoom level indicator up or down, or you can pinch to change zoom level. 2.
  • Page 162 4-4 Interference Map IA Spectrum Analyzer (Option 24) STATUS Panel (Interference Map and Interference Polar) This Status panel is unique to Interference Map and Interference Polar measurement modes (selected via MEASURE > MEASUREMENT menu) of IA Spectrum Analyzer. LAT: Shows the latitude coordinate of the interferer. LON: Shows the longitude coordinate of the interferer.
  • Page 163 IA Spectrum Analyzer (Option 24) 4-4 Interference Map SETUP Menu (Interference Map) The Interference Map SETUP menu is available in MEASURE > MEASUREMENT > Interference Map> SETUP. BEARING SOURCE: Selects the bearing source either as antenna or manual. If antenna is selected the electronic compass from the MA2700A InterferenceHunter is used to find the direction of the peak signal.
  • Page 164 4-5 Interference Polar IA Spectrum Analyzer (Option 24) Interference Polar This section describes the Interference Polar capability and key characteristics of Interference Polar measurement mode. This is an alternative technique to geo-locate a potentially interfering signal without having to go to multiple locations. The user stands at a fixed location and makes a full rotation along with the MA2700A handheld InterferenceHunter and a directional antenna through 360º.
  • Page 165 IA Spectrum Analyzer (Option 24) 4-5 Interference Polar 1. The map zoom tool is used to increase (+) or decrease (-) zoom level. You can also drag the zoom level indicator up or down, or you can pinch to change zoom level. 2.
  • Page 166 4-5 Interference Polar IA Spectrum Analyzer (Option 24) SETUP Menu (Interference Polar) The Interference Polar SETUP menu is available in MEASURE > MEASUREMENT > Interference Polar > SETUP. INTEGRATION BW: Sets the range of integration used in calculating the received power.
  • Page 167 IA Spectrum Analyzer (Option 24) 4-6 Saving and Recalling Measurements Saving and Recalling Measurements The Field Master Series can save measurement setups, native trace and CSV trace data, limit line setups, and screenshots. You can recall setup, native trace, and limit line files. For other file operations such as copy, move, and directory management, refer to File Management section of the product’s user guide.
  • Page 168 4-6 Saving and Recalling Measurements IA Spectrum Analyzer (Option 24) Recalling a Measurement You can recall a saved setup, native trace measurement, and a limit line. When recalling a setup, the instrument setup and operating state will be restored as it was when the setup was saved. When recalling a trace measurement, the instrument setup and on-screen measurement data will be restored as it was when the trace data was saved.
  • Page 169 IA Spectrum Analyzer (Option 24) 4-6 Saving and Recalling Measurements FILE Menu QUICK SAVE: saves a setup file immediately with the name shown in the button. The number in the name is incremented automatically so that the new name is ready for the next setup file to be saved.
  • Page 170 4-6 Saving and Recalling Measurements IA Spectrum Analyzer (Option 24) SAVE ON EVENT Menu Save on event saves the current trace data to a folder named with the current date and time (yyyymmddhhmmss). LIMIT CROSSED: When enabled, measurement trace data is automatically saved when the trace crosses a limit line that has been specified in the LIMIT menu.
  • Page 172 Anritsu Company 490 Jarvis Drive Anritsu utilizes recycled paper and environmentally conscious inks and toner. Morgan Hill, CA 95037-2809 http://www.anritsu.com...

This manual is also suitable for:

Field master ms2080aField master ms2070aSite master ms2089aMs27201aField master pro ms2090a
