8. Operation
8.11.7 Talkback
Fader Strips (Talk to Source)
You can talk to any of the following sources by pressing the TB key on the corresponding fader strip:
·
Guest mics: MIC 2 to 10
·
Hybrids: LINE IN 1 to 4
·
RAVENNA CODECS: RAV 1 to 8
In addition, you can talk to the Guest or Studio Monitoring outputs by pressing the TB keys at the top of the
Central Module.
The TB keys are momentary, so hold the key down for as long as you wish to speak. TALK to ALL (on the
Central Module) talks to the Guest and Studio monitoring outputs, and all available N-1s.
The talkback source is always MIC 1. The talkback level can be adjusted from the TB control at the top of the
Central Module.
When talkback is added to the return, the main signal is dimmed by 20dB.
ruby standard configuration User Manual
Central Module (Talkback Functions)
Version: 6.4.0/2
95/179
