11. Appendices
11.5 The 12V DC Power Supply
12V DC Power Supply (955/50-80)
Dimensions and Weight
Parameter
Mechanical data
Width
Height
Length
Weight
Cable length
Electrical Specification
Parameter
Input Voltage
Frequency
Input Current
Inrush Current
Efficiency
Output Voltage
Output Current
Leakage Current
ruby standard configuration User Manual
Conditions
without plug
Conditions
Version: 6.4.0/2
DC Plug Pinning
Unit
72 mm
35 mm
175 mm
670 g
1200 mm
Min. Typ. Max. Unit
85 264 VAC
47 63 Hz
1,85A/115VAC
AAC
1A/230VAC
120A/230VAC AAC
89 %
12±5% VDC
11.5 ADC
0,75 mA
