8. Operation
Ø
To store settings in a local memory:
1. Press and hold UNLOCK followed by SNAP SAVE.
If a memory has been used, then the numbered buttons, 1 to 5, illuminate in red. A green button indicates a
free memory. If you select a used memory, then its contents will be overwritten.
2. Keep holding SNAP SAVE and select a memory - e.g. number 4.
The SNAP SAVE button flashes magenta to indicate a successful operation.
Ø
To recall settings from a local memory:
1. Press and hold UNLOCK followed by SNAP LOAD.
You can see which memories contain data by looking at the lit buttons.
2. Keep holding SNAP LOAD and select a memory - e.g. number 4.
The SNAP LOAD button flashes magenta to indicate a successful operation and the console resets.
Ø
To clear a local snapshot memory:
1. Press and hold UNLOCK followed by both SNAP LOAD and SNAP SAVE.
You can see which memories contain data by looking at the lit buttons.
2. Keep holding SNAP RECALL and SNAP STORE and select a memory - e.g. number 4.
The snapshot memory if cleared.
3. To check if the operation has been succesful, press and hold SNAP RECALL - the memory number
should now be clear (unlit).
8.16.3 Saving a DisplayDock Snapshot
When you save a DisplayDock snapshot, you can choose to save either a Full snapshot (to save settings
globally across the console) or Source snapshot (to save only the settings for the source in access). The
SAVE SNAP button (on the DOCK) supports both operations as follows.
Ø
To save a Full snapshot:
1. Check that there is no source in access and select SAVE SNAP - the "Save Snapshot" window
appears:
2. Enter a snapshot name (e.g. Guests Automix) and select OK - the window closes and the settings are
saved.
Note that the snapshot Group and Type cannot be changed. You can enter text to describe the snapshot into
the Comment field if you wish.
