8.9.2 Adjusting Source Parameters
1. Select the source you wish to work on by pressing its fader strip ACCESS key - the key turns white.
The upper controls on the Central Module switch into "parameter control" mode, and on DisplayDock the
"Source Parameters" page appears:
DisplayDock shows all available parameters, and so this is the best way to get an overview of a source.
The surface controls are paged through different parameter sets using the INP, DYN, LIM, DLY and EQ
keys on the Central Module.
72/179
DisplayDock (Source Parameters page)
Control Surface (INPUT parameters)
