LAWO Ruby standard configuration User Manual page 18

Generic IO Cards (Slots 3 to 8)
Slot Number
3
4
5
6
7
8
Generic IO Cards (Slots 3 to 8)
Slot Number
3
4
5
6
7
8
5.3.2 RAVENNA Inputs
RAVENNA/AES67 Port A (ra0)
RAVENNA Input Number
1/2... 63/64
5.3.3 RAVENNA Outputs
RAVENNA/AES67 Port A (ra0)
RAVENNA Output Number
1/2
3/4
5/6
7/8
9/10
11/12
13/14
15/16
17/18
19/20
21/22
23/24
25/26
27/28
29... 64
18/179
Input Number
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
Output Number
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
1/2... 7/8
Rx Stream Name
RAV In 1... 32
Tx Stream Name
RAV PGM 1
RAV PGM 2
RAV PGM 3
RAV PGM 4
RAV AUX 1
RAV AUX 2
N-1 RAV 1
N-1 RAV 2
N-1 RAV 3
N-1 RAV 4
N-1 RAV 5
N-1 RAV 6
N-1 RAV 7
N-1 RAV 8
additional Tx streams must be created using the RAVENNA Web UI.
Version: 6.4.0/2
Source Name
IN 01... IN 04
IN 05... IN 08
IN 09... IN 12
IN 13... IN 16
IN 17... IN 20
IN 21... IN 24
Local Matrix Name
OUT 01... OUT 04
OUT 05... OUT 08
OUT 09... OUT 12
OUT 13... OUT 16
OUT 17... OUT 20
OUT 21... OUT 24
Source Name
RAV 01... 32
Format
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
left/right
ruby standard configuration User Manual
5. Specification
Format
stereo
stereo
stereo
stereo
stereo
stereo
Format
stereo
stereo
stereo
stereo
stereo
stereo
Format
left/right
Default Audio from
PGM 1
PGM 2
PGM 3
PGM 4
AUX 1
AUX 2
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
N-1 / N-1+TB
