5. Specification
5.3 Default Audio Assignments
The tables which follow list the default audio assignments for the inputs and outputs.
For the inputs, the source assignments are fixed and cannot be changed by the user. Instead, you can choose
which inputs are active in the mix by changing the fader strip
For the outputs, the configuration loads the default audio assignments. These can be modified from the
matrix (in DisplayDock).
5.3.1 IO Cards (Rear Panel)
Slots 1 and 2 are always fitted with a STUDIO IO card (slot 1) and a MIC/LINE IN card (slot 2). The MIC/LINE
IN card has inputs only; the STUDIO IO card provides both inputs and outputs.
Slots 3 to 8 can be equipped with additional LINE IN, LINE OUT or AES3 IO (as described earlier). If a slot is
fitted with an output-only card, then the corresponding sources will have no audio input! Similarly, if a slot is
fitted with an input-only card, then the corresponding destinations have no audio output!
STUDIO I/O (Slot 1)
Input Number Source Name
1 MIC 1
2 MIC 2
STUDIO I/O (Slot 1)
Output
Line 1/2
HP 1 L/R
HP 2 L/R
MIC/LINE IN (Slot 2)
Input Number Source Name
1 MIC 3
2 MIC 4
3 MIC 5
4 MIC 6
5 MIC 7
6 MIC 8
7 MIC 9
8 MIC 10
ruby standard configuration User Manual
Local Matrix Name
LINE OUT
HP 1
HP 2
Version: 6.4.0/2
assignments on the surface.
Format
mono
mono
Format
left/right
left/right
left/right
Format
mono
mono
mono
mono
mono
mono
mono
mono
local
Default Audio from
MON CR
MON HP
MON GUEST
