Gate
Surface Controls (Gate)
The following parameters are available for the gate:
·
DYN - on/off for all dynamics sections: compressor, expander, gate (and de-esser/automix).
·
GATE - on/off for the gate.
·
THRS - threshold from -93dB to +27dB.
·
ATT - attack time from 0.16ms to 82ms.
·
RLS - release time from 10ms to 5000ms.
For the ATT/RLS control, turn to adjust the attack time, and then press down and turn to adjust the release time.
Both DYN and GATE must be enabled (red) for the expander to be active. This is best checked by looking
at DisplayDock (where you can see the DYN button plus on/off for the individual sections: COMP, EXP,
GATE, etc.)
80/179 Version: 6.4.0/2
8. Operation
DisplayDock
