LAWO Ruby standard configuration User Manual page 145

9. The Web UI
9.7.7 Streams Tab
This tab lists all available network streams which have been announced to Power Core.
Clicking on a name in the "Stream Name" column opens a pop-up where you can view and copy the stream's
SDP.
Pay particular attention to the stream "State Flags" which show the condition of the stream. There is a key at
the bottom of the page which explains the meaning of each flag.
Above the flag descriptions is the Update selector. This can be set to one of two possibilities: Data only (the
default) or Data + TTL. This works in a similar manner to the Update function in the
are reset to the "Streams List TTLs" value (defined in ON-AIR Designer).
ruby standard configuration User Manual Version: 6.4.0/2
Nodes Tab, but the TTLs
145/179
