6.1 Installing the Control Surface
Packing List
6.1.1
Each control surface frame ships with the following additional items:
·
1 x external 12V DC power supply - to power the frame.
·
1 x 2m IEC power cable (country-specific) - to connect mains to the 12V DC power supply.
·
1 x 3m RJ45 cable - to connect the CAN bus from the surface to Power Core or another frame.
·
Printed sheets with "OFF" key foil printed labels (required for Button Start consoles only) - to re-label
the fader strip MF Keys.
If the surface consists of multiple frames, then you will receive one set of accessories per frame (as every
frame requires its own power, CAN bus and MF Key labels).
6.1.2 Preparation
A single control surface can consist of one or more frames.
Unpacking
Each frame is delivered in its own box with all included accessories.
Please check the contents of the shipping boxes, and in the event of any transport damage, contact your local
Lawo representative or email support@lawo.com. A list of serial numbers for all components is included with the
shipment. Please keep this list for your records.
Dimensions and Weight
The dimensions and weight of the frame depend on its size and version: table-top, countersunk or countersunk
short. Drawings for all frame variants are available from the Downloads area at
Temperature and Cooling
The control surface is designed for normal studio installation and needs no special air conditioning.
Power Consumption & Electrical Voltage
Please see the 12V DC Power Supply
22/179
appendix.
Version: 6.4.0/2
6. Installation
www.lawo.com (after Login).
