5.4 GPIO Functions
The tables below describe the functionality provided by the GPIO connector. 8 x GPI (opto-couplers) and 8 x
GPO (silent and self-healing CMOS relays) are supported.
GPI Function Name
1 MIC 2 ON / OFF / COUGH
2 MIC 3 ON / OFF / COUGH
3 MIC 4 ON / OFF / COUGH
4 MIC 2 TALK
5 MIC 3 TALK
6 MIC 4 TALK
7 INCOMING CALL INPUT 1
8 INCOMING CALL INPUT 2
GPO Function Name
1 REDLIGHT CR
2 REDLIGHT STUDIO
3
4
5 INPUT 1 ON
6 INPUT 2 ON
7 PGM 1 SILENCE
8 MIC 1 "ON" TALLY
20/179
Logic
ON / OFF toggle; if ON and "push and hold" (400 ms) > mute
ON / OFF toggle; if ON and "push and hold" (400 ms) > mute
ON / OFF toggle; if ON and "push and hold" (400 ms) > mute
INPUT MUTE MIC; > DJ HP and CR
INPUT MUTE MIC; > DJ HP and CR
INPUT MUTE MIC; > DJ HP and CR
HYBRID 1 (LOCAL)
HYBRID 2 (LOCAL)
Logic
HYBRID 1 (LOCAL)
HYBRID 2 (LOCAL)
