ICP-CC408 | Installation Guide | 17.0
This feature is useful, for example, when someone
places objects in the view of a motion detector, which
prevents the detector from picking up movement.
17.8

Codepad Lockout Time

Location 410
0 No lockout
1 to 15 Lockout time (increments of 10 sec)
All codepads are locked out for the programmed
time if an invalid code is entered more times than
allowed by the code retry attempts programmed in
Location 356 (refer to Section 15.19 System Status –
Access Denied on page 67). If the Codepad Lockout
Time is programmed as 0, codepad lockout does not
occur.
17.9

Siren Run Time

411
Location
Default 5
0 No siren time
1 to 15 Siren time in min
The Siren Run Time determines how long the horn
speaker operates during an alarm. You can program
the Siren Run Time from 0 to 15 min in 1-min
intervals.

17.10 Siren Sound Rate

Location 412
Default 7
0 Slowest frequency
15 Fastest frequency
The Siren Sound Rate varies the frequency of the
siren tone slowest (0) and to fastest (15). The Siren
Sound Rate does not change the frequency of the fire
alarm tone.

17.11 Auto Arming Pre-Alert Timer

413
Location
Default 1
0 No alert time
1 to 15 Alert time (increments of 5 min)
This location sets the time period during which the
control panel warns you it is automatically armed in
AWAY Mode. The codepad beeps once every
second until the Pre-Alert Timer expires; the system
then automatically arms itself in AWAY Mode. If
you want the system to automatically arm in STAY
Mode 1, enable Option 4 in Location 428 (refer to
Section 18.5 Consumer Options 1 on page 80).
After the control panel is automatically armed in
AWAY Mode or STAY Mode 1, Exit Time starts. If
a valid User Code is entered during the Pre-Alert
Time, the Auto Arming Time programmed in
Locations 414 to 417 (refer to Section 17.12 Auto
Arming Time on page 77) is extended by 1 hour.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Event Timers
If you want a programmable output to operate
during the Auto Arming Pre-Alert Time, use Output
Event Type 0,5 Auto Arm Pre-Arming Alert Time (refer
to page 69).

17.12 Auto Arming Time

414 to 417
Location
Hour of the day (tens digit)
Hour of the day (units digit)
Minute of the day (tens digit)
Minute of the day (units digit)
These locations specify the time of the day that the
system automatically arms itself in AWAY Mode. Set
this time in 24-hour format (for example, program
10:30 PM as 2230). If you want the system to arm in
STAY Mode 1, select Option 4 in Location 428 (refer
to Section 18.5 Consumer Options 1 on page 80).
If forced arming is disabled for any zone, the
automatic arming feature operates regardless of
whether any zones are unsealed. Refer to Section
14.3.7 Zone Options 2 on page 62 for more
information on programming zones for forced
arming.
User Code 16 is reported when this feature is used.
For partitioned ICP-CC408 Control Panels, both
areas are automatically armed in AWAY Mode at the
same time each day.

17.13 Auto Disarming Time

Location 418 to 421
Hour of the day (tens digit)
Hour of the day (units digit)
Minute of the day (tens digit)
Minute of the day (units digit)
These locations specify the time of day that the
system automatically disarms itself. Set this time in
24-hour format (for example, program 10:30 PM as
2230).
User Code 16 is reported when this feature is used.
For partitioned ICP-CC408 Control Panels, both
areas are automatically disarmed at the same time
each day.

17.14 Kiss-Off Wait Time

Location 422
Default 3
Increments of 500 ms (500 ms to 8 sec)
This location sets the time that the control panel
waits for acknowledgment before resending a report.
This timer applies only to the 4 + 2 Express Format.
EN | 77
Location Default
414 0
415 0
416 0
417 0
Location Default
418 0
419 0
420 0
421 0
