ICP-CC408 | Installation Guide | 6.0
Example
If the events occurred in the following order:
Table 38: Event Sequence
Sequence
Event
1
System armed in AWAY Mode
2
Alarm in Zone 3
3
Alarm in Zone 4
4
System disarmed
The alarm memory is played back in this order:
Table 39: Event Memory Playback
Sequence
Indication
1
All indicators off
except MAINS
2
Zone 4 and AWAY
indicators light
3
Zone 3 and AWAY
indicators light
4
AWAY indicator
lights
Each event is indicated by a beep and a lit indicator.
Resetting a disarmed 24-Hour Alarm is indicated by
a beep only.
After the last event, three beeps sound to indicate the
end of playback. You can stop the replay at any time
by pressing [AWAY].
If the system is armed in STAY Mode 1 or
STAY Mode 2, the STAY indicator shows
the event memory playback. There is no
differentiation between STAY Mode 1
and STAY Mode 2.
If the control panel is powered down, the
memory of all events is saved.
6.3
User Code Functions
6.3.1
Arming or Disarming Both Areas at the
Same Time
This User Code function operates only with
partitioned ICP-CC408 Systems and allows User
Codes allocated to both Area 1 and Area 2 to arm or
disarm both areas at the same time.
This feature allows a user to arm or disarm the
system by pressing one extra button rather than
entering a code twice. You can use either the CP5
Area Addressable Codepad (CP500AW) or the
Master Partitioned Codepad (CP500PW) with this
function. To enable this feature, select Option 2 in
Location 433 (refer to Section 19.3.2 Partitioning
Options 2 on page 83).
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Functions
To arm or disarm both areas at the same time:
Enter your User Code and press [0][AWAY].
Two beeps sound and both areas are armed or
disarmed from AWAY Mode.
6.4
Hold-down functions allow easy activation of specific
operations. When you hold down a button for 2 sec,
two beeps sound and the corresponding function
operates. The hold-down functions are listed below.
6.4.1
Holding [#] down until two beeps sound arms the
system in AWAY Mode. This hold-down function
operates only if you select Option 2 in Location 429
(refer to Section 18.6 Consumer Options 2 on page 81).
Event
System disarmed
Alarm in Zone 4
Alarm in Zone 3
System armed in
AWAY Mode
6.4.2
Holding [*] down until two beeps sound arms the
system in STAY Mode 1. This hold-down function
operates only if you select Option 2 in Location 429
(refer to Section 18.6 Consumer Options 2 on page 81).
If there was no alarm during the armed cycle,
holding down [*] a second time disarms the system
from STAY Mode 1. To enable single button
disarming from STAY Mode 1 using this hold-down
function, select Option 4 in Location 429.
If an alarm occurred or entry warning was activated,
a valid User Code is required to disarm the system.
Refer to Section 14.3.7 Zone Options 2 on page 62 for
information on programming each zone to be
automatically isolated in STAY Mode 1.
6.4.3
Holding down [0] until two beeps sound arms the
system in STAY Mode 2. This hold-down function
operates only if you select Option 2 in Location 429
(refer to Section 18.6 Consumer Options 2 on page 81).
Hold-Down Functions
Arming the System in AWAY Mode
This hold down function does not work if
you are using a CP5 Master Partitioned
codepad (CP500PW) with a partitioned
ICP-CC408 Control Panel.
If you are using a CP5 Area Addressable
codepad (CP500AW) with a partitioned
ICP-CC408 Control Panel, this function
arms the corresponding area in AWAY
Mode.
Arming the System in STAY Mode 1
This hold-down function does not work if
you are using a CP5 Master Partitioned
Codepad (CP500PW) with a partitioned
ICP-CC408 Control Panel.
If you are using a CP5 Area Addressable
Codepad (CP500AW) with a partitioned
ICP-CC408 Control Panel, this function
arms the corresponding area in STAY
Mode1.
Arming the System in STAY Mode 2
EN | 39
