- Page 1 Control Panel ICP-SOL2-P/ICP-SOL3-P User's Guide...
-
Page 3: Table Of Contents
Date and Time Turning Outputs On/Off Reset Latching Outputs 5.10 Telco Arm/Disarm Sequence (Call Forward On/Off) 5.10.1 Telco Arm Sequence 5.10.2 Telco Disarm Sequence 5.11 Testing 5.11.1 Horn Speaker Test Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... - Page 4 Codepad ID / Buzzer Tone 5.15 Remote Arming by Telephone 5.16 Domestic Dialing 5.16.1 Acknowledging Domestic Calls 5.16.2 Programming Domestic Telephone Numbers 5.16.3 Disable Domestic Dialing Glossary of Terms 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc.
-
Page 5: Introduction
Introduction | en Introduction Congratulations on selecting the ICP-SOL2-P/ICP-SOL3-P Control Panel to protect you and your property. To obtain the most from your unit, take time to read through this manual and familiarize yourself with the numerous outstanding operating features of this system. In all aspects of planning, engineering, styling, operation, convenience, and adaptability, we have sought to anticipate your every possible requirement. -
Page 6: Specifications
Dimensions (Case, packed in carton) 306 mm x 262 mm x84 mm Weight 2.5 kg Supplier Code N771 Table 2.1: Specifications Notice! Test the sirens, strobe, and zones at weekly intervals. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 7: Codepad Introduction
System is armed in AWAY Mode. System is not armed in AWAY Mode. AWAY Flashing twice a sec with Setting STAY Mode 2 zones. STAY indicator Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... - Page 8 The ON indicator lights when the system is armed and flashes when an alarm occurs. The indicator is reset after a valid User Code is entered. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc.
-
Page 9: Audible Indications
During Auto Arming Pre-Alert Time, the warning before automatic arming takes place. One beep every 2 sec. During Exit Time when armed in AWAY Mode. Table 3.1: Audible Indicators Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 10: Operation With Text Lcd Codepad
[ U ] 139 System Reset [ I ] 14 RF Diagnose [ I ] 141 RF Zone [ I ] 142 RF Keyfob [ I ] 143 RF Repeater 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 11: Access Menu
[ I ] 334 Disarmed On Power Up [ I ] 335 Arm/Disarm Track On Power Up [ I ] 336 Phone Remote Arm [ I ] 337 Answer Machine Bypass On Arm Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 12: Zone Menu
[ I ] 491 Silent Zone Tamper Alarm [ I ] 492 Unseal Zone That Fail Monitor [ I ] 493 Bosch Smart Lockout Enable [ I ] 494 Zone Pulse Cnt Handover Enable [ I ] 495 Handover Delay In Order Table 4.5: Zone Menu... -
Page 13: Area Menu
[ I ] 736 Test Report Time And Interval [ I ] 737 Test Report Only When Armed [ I ] 738 Test Report On Siren Reset [ I ] 739 Test Report Dialer Option Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 14: Parameter Menu
[ I ] 82 Addr Auto Step [ I ] 83 Adapter [ I ] 831 Test Adapter [ I ] 832 Read Adapter [ I ] 833 Write Adapter Table 4.9: Parameter Menu 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 15: Operation With Icon Lcd Codepad
Method Two Hold down the [#] button until two beeps sound. The AWAY indicator displays and Exit Time starts counting. Table 5.2: How to Arm the System in AWAY Mode Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 16: Arming In Stay Mode 1
Any zones programmed to be automatically isolated in STAY Mode 2 flash until Exit Time expires. At the end of Exit Time, all zones selected to be automatically isolated extinguish and the codepad emits one short beep. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 17: Programming Stay Mode 2 Zones
Enter the user code number (1 to 32), followed by the [#] button (for example, [2#] = User 2, [16#] = User 16). Two beeps sound and the selected user number displays on the codepad indicators. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 18: Codepad Alarms
Standard isolating allows all operators to isolate zones without knowing a valid user code. How to Isolate a Zone Press the [*] button twice to enter the Isolating Mode. Three beeps are heard and the STAY indicator flashes. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 19: Code To Isolate
To exit Fault Analysis Mode and return to the disarmed state, press the [#] key. The FAULT indicator continues to display and the codepad stops sounding once a min. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 20: Fault Descriptions
Power Supply Fail – This fault occurs when AUX power supplies fails, +12V power fails, or SDI2 Bus power fails. Contact your installer as soon as this fault displays. Tamper – This fault occurs when the system detects the control panel is tampered. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 21: Date And Time
Press the [#] button to exit and return to the disarmed state. Two beeps sound, and the STAY and AWAY indicators turn off. If a long beep sounds, an error was made when entering the date and time. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 22: Turning Outputs On/Off
Press the [#] key when finished. Two beeps sound, and the STAY and AWAY indicators turn off. Notice! To disable the Telco Arm Sequence, enter the Call Forward Sequence as [*5] (terminator) for Step 3. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 23: Telco Disarm Sequence
Hold the [1] key until two beeps sound. The horn speaker sounds for 2 sec. 5.11.2 Bell Test Hold the [2] key until two beeps sound. The bell output operates for 2 sec. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 24: Strobe Test
Hold down the [8] key until the desired buzzer tone is reached. Press the [#] key to exit. There are 50 different tones, from1500 Hz to 5000 Hz. If multiple codepads are installed, each codepad can have a different tone. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 25: Remote Arming By Telephone
Pressing the [*] key for 1 sec to 3 sec during the pause acknowledges the call. No further calls are made for that event. If the call was successfully acknowledged, a tone of decreasing pitch sounds. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... -
Page 26: Programming Domestic Telephone Numbers
Enter the telephone number you need to cancel and press the [#] keys (for example, [1#]). Press the [*] key followed by the [5] and [#] keys(for example, [*5#]). The STAY and AWAY indicators are disabled. 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc. -
Page 27: Glossary Of Terms
Zones 3 and 4. This is known as sequential hand-over delay. hand-held radio A device used to arm and disarm a security system or to cause a panic remote control alarm. Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028... - Page 28 A monitored input used to activate an alarm. A zone might be set up to activate an alarm only when the system is armed or to operate whether the system is armed or disarmed. Table 6.1: Glossary of Terms 2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc.
