ICP-CC408 | Installation Guide | 7.0
To determine the area to which the codepad
belongs:
1. Press and hold [8] until two beeps sound.
A zone indicator lights to show the area to which
the codepad belongs.
Zone 1 = Area 1 codepad
Zone 2 = Area 2 codepad
Zone 7 = Master Partitioned Codepad
If no zone indicator lights, the codepad set up
incorrectly or an incorrect codepad is used.
2. Press [AWAY] to exit from this mode.
6.4.12
Send Test Report
Holding down [9] until two beeps sound transmits a
Test Report (Contact ID Event Code 602) to test the
dialing and reporting capabilities of the system
without activating the sirens.
7.0
Remote Arming by
Telephone
This feature allows you to arm your system from any
remote location by telephone. For obvious security
reasons, you cannot disarm the system using this
method. A touch-tone telephone is required to use
this feature.
To remotely arm your system by telephone:
1. Call the telephone number to which your control
panel is connected.
When the control panel answers the incoming
call, a short jingle sounds.
If you hear a number of strange sounding
tones when the control panel answers the
incoming call, the system is programmed
for remote programming functions. Wait
for a pause in the tones and follow Step 2
to arm the system remotely.
2. Press and hold [*] on the touch-tone telephone
for 3 sec to arm the system.
Two beeps sound to indicate that the system is
armed in AWAY Mode.
3. Hang up the telephone.
The system remains armed.
If the control panel does not answer the call, the
system might be armed already, remote functions are
not enabled, or the ring count is set to 0. To enable
remote arming by telephone, select Option 2 in
Location 177 (refer to Section 12.1 Dialer Options 1 on
page 53). To set the number of rings before the
control panel answers, refer to Section 11.10 Ring
Count on page 41.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Remote Arming by Telephone
When both Remote Arming and
Upload/Download are selected, the
control panel answers the call expecting
the remote computer. When this occurs,
modem negotiating tones sound rather
than the remote arming jingle.
Using this method with a partitioned
ICP-CC408 Control Panel arms both
areas in AWAY Mode. Arming individual
areas is not available with this method.
8.0 Alarm Link Software
You can program or control the ICP-CC408 Control
Panel remotely using an IBM or compatible personal
computer and the CC816 Alarm Link Software. This
software allows you to change your customer's
control panel without leaving your office, which
improves customer service and saves you time and
money. For locations where a control panel is
installed hundreds of kilometres from your office, the
Upload/Download feature is invaluable.
When selecting the control panel type during the
setup of a new customer database in the Alarm Link
Software, refer to Table 40 to select the software
version number corresponding to the control panel
type.
Table 40: Alarm Link Panel Forms
Control Panel
Software Version
ICP—CC408 v1.0x
When adding a new customer in the Alarm Link
Software, the Subscriber ID Number and the Installer
Code must match the values programmed in the
control panel for synchronisation when connecting to
the control panel. If these two locations do not match
those of the control panel, the computer and the
control panel cannot be synchronized.
8.1
Remote Connect
The remote connect feature allows you to establish a
connection through the telephone network from your
IBM or compatible computer to the ICP-CC408
Control Panel. This software allows you to offer
faster service to your clients.
8.1.1
Remote Connect with Customer
Control
If you want to configure the control panel so that a
remote connection can be established only when the
client initiates it through the remote codepad,
program the following information:
•
Program the Call Back Telephone Number in
Locations 159 to 174 (refer to Section 11.9 on
page 51).
EN | 41
Select Panel Type
I408_V10
