ICP-CC408 | Installation Guide | 5.0
5.2
Remote Radio User Code Priority
Levels
You can only program the remote radio hand-held
transmitters to operate as User Codes 9 to 16. You
can assign priority levels to each hand-held
transmitter, for example, allowing the transmitter to
arm the system only, or to arm and disarm the
system. Refer to Section 13.3 User Code Priority on
page 55 for more information.
Before a hand-held radio transmitter can operate the
control panel, you must teach the transmitter's radio
code to the control panel. Refer to Section 5.3
Changing or Deleting Remote Radio User Codes on page
26 for more information.
5.3
Changing or Deleting Remote
Radio User Codes
You can use up to eight remote radio hand-held
transmitters (User Codes 9 to 16) to operate the
system. Before the control panel accepts a signal
from a remote radio hand-held transmitter, the
control panel must learn the transmitter's code.
You can substitute the Installer Code for
the Master Code to change or delete
remote radio User Codes.
To add or change a remote radio User Code:
1. Enter the Master Code and press [1][AWAY].
Three beeps sound and the STAY and AWAY
indicators flash.
2. Enter the user number (9 to 16) you want to add
or change and press [AWAY].
Two beeps sound and the corresponding zone
indicators light. Refer to Table 21.
Table 21: Codepad Indicators for Remote
Radio User Numbers
Data
Zone Indicators
Value
1
2
3
9
X
10
11
X
12
X
13
X
14
15
16
3. Press any of the [TRANSMIT] buttons on the
hand-held transmitter to allow the control panel
to learn transmitter's ID code.
Two beeps sound and the STAY and AWAY
indicators are extinguished.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Remote Radio Transmitter Operations
4
5
6
7
8
MAINS
X
X
X
X
X
X
X
X
X
X
X
4. Repeat Steps 1 through 3 to add or change
another remote radio User Code.
This function is automatically terminated if
you do not press a button within 60 sec
or if you press [AWAY].
One long beep indicates that the code
already exists or you selected an incorrect
user number.
When using a partitioned ICP-CC408
Control Panel, you must allocate the
remote radio User Codes to one or more
areas (refer to Section 19.5 User Code
Allocations on page 84).
To delete a remote radio User Code:
1. Enter the Master Code and press [1][AWAY].
Three beeps sound and the STAY and AWAY
indicators flash.
2. Enter the user number (9 to 16) you want to
delete and press [AWAY].
Two beeps sound and the corresponding zone
indicators light. Refer to Table 21 on page 26.
3. Press [STAY] to delete the User Code.
Two beeps sound and the STAY and AWAY
indicators are extinguished.
4. Repeat Steps 1 through 3 to delete another
remote radio User Code.
This function is automatically terminated if
you do not press a button within 60 sec
or if you press [AWAY].
One long beep indicates that you
selected an incorrect user number.
5.4
2-Channel Remote Radio Hand-
Held Transmitter Operations
Because all operations using the 2-button remote
radio hand-held transmitter are fixed after the control
panel learns the transmitter's code, no programming
is required for the transmitter buttons.
EN | 26
