ICP-CC408 | Installation Guide | 18.0
4 – Zone Pulse Count Handover
If this option is selected, any zone pulse count
readings are handed over and accumulate to any
zone that is activated during the same arming cycle.
Zone pulse count handover operates only with zone
pulse count options 8 to 15. Refer to Section 14.3.3
Zone Pulse Count on page 60 and Section 14.3.4 Zone
Pulse Count Time on page 60 for more information.
24-Hour Zones will receive all handover
pulses from other zones. 24-Hour Zones
cannot hand over pulses to other zones.
8 – Handover Delay To Be Sequential
If this option is selected, handover delay is sequential
(that is, in numerical order from lowest to highest). If
the sequence is broken before the Entry Time
expires, an alarm occurs. If this option is not selected,
handover delay follows the entry path if a Delay
Zone is activated first. Refer to Section 14.3.2 Zone
Types on page 58 for more information about
Handover Zones.
18.4
System Options 4
Location
427
0
Default
1
Panel to power up disarmed (if power reset)
2
Arm/disarm tracking on power up
4
Internal crystal to keep time
8
Night arm station, or RE005/E installed
1 – Panel To Power Up Disarmed
If this option is selected, the control panel powers up
in the disarmed state when the battery and AC
MAINS are reconnected after the system is powered
down.
If this option is not selected, the system is always
powered up armed in AWAY Mode.
2 – Arm/Disarm Tracking on Power Up
If selected, the control panel keeps its current armed
status in non-volatile memory. If the control panel is
restarted due to a power failure, the control panel
returns to being armed or disarmed as it was before
the power failed.
Example
If the system is disarmed when the system is powered
down, the system returns to the disarmed state when
the system is powered back up.
4 – Internal Crystal To Keep Time
If this option is selected, the control panel uses the
internal crystal (XTAL) to track time. This option is
useful in countries that do not have a constant
MAINS frequency. If this option is not selected, the
control panel uses the MAINS frequency as a time
base to keep time.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System and Consumer Options
8 – Night Arm Station, or RE005/E Installed
Select this option to use the RE005/E 2-Channel
Radio Interface, or the CP105A Night Arm Station.
This option enables any of these three accessories to
operate the control panel. User Code 16 is used to
send Open/Close Reports when you use any of these
accessories.
The Night Arm Station cannot operate a
partitioned ICP-CC408 Control Panel.
18.5
Consumer Options 1
428
Location
Default
0
1
Test reports only when armed
2
Test report after siren reset
4
Auto arm in STAY Mode 1
8
STAY indicator to display Day Alarm status
1 – Test Reports Only When Armed
If this option is selected, Test Reports (Contact ID
Event Code 602) are only sent when the system is
armed. It is no longer necessary to send a Test
Report with an Opening and Closing Report every
day.
Most commercial premises are open during the
working week, so a Test Report is not necessary
because Open and Close Reports are sent at the
programmed time. If you want to manually send a
Test Report, press and hold [9] button until two
beeps sound.
Refer to Section 15.21 Test Reporting Time on page 67
to set the desired Test Report time. To set the first
Test Report, refer to Section 6.1.1 Set the Number of
Days until the First Test Report on page 29.
2 – Test Report after Siren Reset
Select this option to force the control panel to send a
Test Report after the siren is reset. This can be used
to indicate to the monitoring station that the control
panel itself was not tampered with during the alarm
period.
4 – Auto Arm in STAY Mode 1
Select this option if automatic arming in STAY Mode
1 is preferred to automatic arming in AWAY Mode.
Program the time the control panel automatically
arms itself in Locations 414 to 417 (refer to Section
17.12 Auto Arming Time on page 77). Set the Auto
Arming Pre-Alert Time in Location 413 (refer to
Section 17.11 on page 77).
For partitioned ICP-CC408 Control
Panels, both areas are automatically
armed.
EN | 80
