ICP-CC408 | Installation Guide | 18.0
17.15 System Time
901 to 904
Location
Hour of the day (tens digit)
Hour of the day (units digit)
Minute of the day (tens digit)
Minute of the day (units digit)
The ICP-CC408 Control Panel has a real-time
24-hour clock you must set during installation. Set
this time in 24-hour HHMM format (for example,
program 10:30 PM as 2230). You must reset the
System Time every time the system is powered
down.
17.16 System Date
Location
905 to 910
Day of the month (tens digit)
Day of the month (units digit)
Month of the year (tens digit)
Month of the year (units digit)
Current year (tens digit)
Current year (units digit)
The ICP-CC408 Control Panel has a real-time
12-month calendar you must set during installation.
Set the date in DDMMYY format (for example,
program 1 January 2004 as 010104). You must reset
the System Date every time the system is powered
down.
To set the date and time:
1. Enter your Master Code and press [6][AWAY].
Three beeps sound and the STAY and AWAY
indicators flash.
2. Enter the day, month, year, hour, and minute in
DD, MM, YY, HH, MM format (where DD is
the day of the month, MM is the month of the
year, YY is the year, HH is the hour of the day,
and MM minute of the day) and press [AWAY].
Use 24:00 hour format when programming the
hour of the day.
Two beeps sound and the STAY and AWAY
indicators are extinguished. If a long beep
sounds, there was an error when you entered the
date and time.
Example
To set the date and time for the 1st January 2004 at
10:30 PM, enter:
[2 5 8 0 6][AWAY][0 1 0 1 0 4 2 2 3 0][AWAY]
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System and Consumer Options
18.0 System and Consumer
Location
Default
The locations in this section have up to four options.
901
0
You can select any combination of these options by
902
0
programming a single value. Calculate this value by
903
0
adding the option bit numbers together. Refer to
904
0
Section 2.3 Programming Option Bits on page 11 for
more information.
18.1
Location
1
2
4
8
1 – Smart Lockout Allowed
Location
Default
905
0
This feature allows the control panel to remove any
zones that are programmed for lockout dialer from
906
1
the lockout list when the sirens are running. This
907
0
feature allows a monitoring station to receive zone
908
1
alarm reports from previously locked out zones
909
0
during siren time. Refer to Section 14.3.5 Zone Options
910
1
1 on page 60 for information on programming zones
for lockout dialer and lockout siren.
Refer to Section 14.5 Swinger Shutdown Count for Dialer
on page 63 to program the number of times the zone
can report before being locked out.
2 – Horn Speaker Monitor
If this option is selected, the control panel detects
when the horn speaker is disconnected from the
speaker terminals. The FAULT indicator lights when
the horn speaker is disconnected, and is extinguished
when the horn speaker is reconnected.
If an output is required to operate when the horn
speaker is disconnected, use Output Event Type 1,6
Horn Speaker Monitor Fail (refer to page 70 for more
information).
4 – Strobe Indications for Radio Arm/Disarm
This option allows the strobe to indicate when the
system is armed and disarmed when remotely
operating the system using the WE800/E Wireless
On/Off Interface.
Table 62: Strobe Indications for Remote
Strobe Duration
3 sec
6 sec
6 sec
8 – Horn Speaker Beeps for Radio Arm/Disarm
This option enables the horn speaker to sound when
the system is armed or disarmed remotely using the
WE800/E Wireless On/Off Interface.
Options
System Options 1
424
Bosch Security Systems, Inc. smart lockout allowed
Horn speaker monitor
Strobe indications for radio arm/disarm
Horn speaker beeps for radio arm/disarm
Operations
System Status
System disarmed
System armed in AWAY Mode
System armed in STAY Mode 1
EN | 78
