ICP-CC408 | Installation Guide | 18.0
Table 63: Horn Speaker Beeps for Remote
Operations
Tone
1 beep
2 beeps
1 two-tone beep
18.2

System Options 2

Location 425
Default 0
1 Codepad Panic to be silent
2 Codepad Fire to be silent
4 Codepad Medical to be silent
8 Access denied (code retries) to be silent
1 – Codepad Panic To Be Silent
If this option is selected, a Codepad Panic Alarm or
Radio Remote Panic Alarm does not operate the
horn speaker, the bell, or the strobe outputs. If this
option is not selected, all three outputs operate after a
Codepad Panic Alarm is activated when a user
presses [1] and [3] or [STAY] and [AWAY] at the
same time on the remote codepad. Selecting this
option does not affect the operation of the
communication dialer.
If you want to disable reporting of a Codepad Panic
Alarm, program Locations 337 and 338 as 0 (refer to
Section 15.9 Codepad Panic Report on page 65).
2 – Codepad Fire To Be Silent
If this option is selected, a Codepad Fire Alarm does
not operate the horn speaker, the bell, or the strobe
outputs. If this option is not selected, all three outputs
operate after a Codepad Fire Alarm is activated
when a user presses [4] and [6] at the same time on
the remote codepad. Selecting this option does not
affect the operation of the communication dialer.
If you want to disable the reporting of a Codepad
Fire Alarm, program Locations 339 and 340 as 0
(refer to Section 15.10 Codepad Fire Report on page 66).
4 – Codepad Medical To Be Silent
If this option is selected, a Codepad Medical Alarm
does not operate the horn speaker, the bell, or the
strobe outputs. If this option is not selected, all three
outputs operate after a Codepad Medical Alarm is
activated when a user presses [7] and [9] at the same
time on the remote codepad. Selecting this option
does not affect the operation of the communication
dialer.
If you want to disable the reporting of a Codepad
Medical Alarm, program Locations 341 and 342 as 0
(refer to Section 15.11 Codepad Medical Report on page
66).
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System and Consumer Options
System Status
System disarmed
System armed in AWAY Mode
System armed in STAY Mode 1
8 – Access Denied (Code Retries) To Be Silent
If this option is selected, a Codepad Tamper Alarm
does not operate the horn speaker, bell, or the strobe
outputs. If this option is not selected, all three outputs
operate after a Codepad Tamper Alarm occurs.
Refer to Section 15.19 System Status – Access Denied on
page 67 to set the number of invalid code retries that
causes an alarm condition. Selecting this option does
not affect the operation of the communication dialer.
If you want to disable the reporting of Access Denied
reports, program Locations 357 and 358 as 0.
18.3

System Options 3

Location 426
1 AC fail after 1 hour (disabled = after 2 min)
2 Ignore AC fail
4 Pulse count handover allowed
8 Handover delay to be sequential
1 – AC Fail after 1 Hour
If this option is selected, the MAINS indicator flashes
when the AC MAINS supply is disconnected. An AC
Loss signal (Contact ID Event Code 301) is
transmitted to the base station receiver after the AC
MAINS supply is disconnected continuously for
longer than 60 min.
If this option is not selected, the MAINS indicator
flashes and an AC Loss signal (Contact ID Event
Code 301) is transmitted to the base station receiver
after the AC MAINS power is disconnected
continuously for 2 min.
The MAINS indicator stops flashing when the AC
MAINS supply is restored longer than 2 min.
An AC Loss Restore Report is transmitted to the
base station receiver after the AC MAINS supply is
restored continuously for more than 2 min regardless
of whether this option is selected.
2 – Ignore AC Fail
If this option is selected, the MAINS indicator does
not flash and the codepad does not beep every min
when the AC MAINS is disconnected from the
control panel. If you want a programmable output to
operate when the AC MAINS fails, use Output Event
Type 1,4 AC Fail (refer to page 70).
If this option is selected, an AC Loss report (Contact
ID Event Code 301) still reports to the base station
receiver unless Locations 348 and 349 are
programmed as 0 (refer to Section 15.15 System Status
– AC Fail Report on page 66).
