User Code Priority Levels
Priority Description
0 Arm/disarm
1 Arm only
2 Arm/disarm and Open/Close Reports
3 Arm only and Close Report
4 Arm/disarm and code to isolate
6 Arm/disarm, code to isolate, and
Open/Close Reports
8 Arm/disarm and Master Code functions
10 Arm/disarm, Master Code functions, and
Open/Close Reports
12 Arm/disarm, Master Code functions, and
code to isolate
14 Arm/disarm, Master Code functions, code
to isolate, and Open/Close Reports
Day Alarm Zones
Location 265
Default
1 Zone 1
2 Zone 2
4 Zone 3
8 Zone 4
EOL Resistor Value
Location 266
0 No EOL resistor
1 1K (brown, black, red)
2 1K5 (brown, green, red)
3 2K2 (red, red, red)
4 3K3 (orange, orange, black, brown) 1%
5 3K9 (orange, white, red)
6 4K7 (yellow, white, red)
7 5K6 (green, blue, red)
8 6K8 (blue, grey, black, brown) 1%
9 10K (brown, black, orange)
10 12K (brown, red, orange)
11 22K (red, red, orange)
12 Reserved
13 Reserved
14 Reserved
15 Split EOL (3K3/6K8) 1% resistors required.
Eight programmable zones.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Programming Sheets
Zones
Location
Zone 1
Default
Zone 2
Default
Zone 3
Default
Zone 4
Default
Zone 5
Default
Zone 6
Default
Zone 7
Default
Zone 8
Refer to page 56
Default
0
Each zone contains seven locations. The first three
locations determine how the zone operates:
Zone Type
The next two locations contain zone options:
Refer to page 56
The last two locations contain reporting information:
Zone Types
These are the zone types available:
Zone Type
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
267 to 322
Zone Pulse
Count
Zone Options 1
Report Code
Description
Instant
Handover
Delay-1
Delay-2
Reserved
Reserved
24-Hour Medical
24-Hour Panic
24-Hour Holdup
24-Hour Tamper
Reserved
Keyswitch
24-Hour Burglary
24-Hour Fire
Chime only
Zone not used
EN | 100
Refer to page 58
Locations 267 to 273
2 0 0 1 14 1 1
Locations 274 to 280
1 0 0 1 14 1 1
Locations 281 to 287
1 0 0 1 14 1 1
Locations 288 to 294
1 0 0 1 14 1 1
Locations 295 to 301
0 0 0 1 14 1 1
Locations 302 to 308
0 0 0 1 14 1 1
Locations 309 to 315
0 0 0 1 12 1 1
Locations 316 to 322
9 0 0 1 12 1 1
Zone Pulse
Count Time
Zone Options 2
Dialer Options
