ICP-CC408 | Installation Guide | 13.0
12.3
Dialer Options 3
179
Location
0
Default
1
Set DTMF dialing pulses to 1 digit/sec
2
Reserved
4
Change decadic dialing to 60/40
8
Reserved
1 – Set DTMF Dialing Pulses to 1 Digit/Sec
If this option is not selected, the Australian DTMF
dialing format dials at 5 digits per sec (that is, 100 ms
tone, 100 ms pause, 100 ms tone, 100 ms pause).
If this option is selected, the Australian DTMF
dialing format dials at the rate of 1 digit per sec (that
is, 500 ms tone, 500 ms pause).
4 – Change Decadic Dialing to 60/40
Some countries have different requirements for
decadic dialing. Selecting this option changes the
dialing characteristics from 65/35 (Australian
Standard) to 60/40. Select this option only when the
control panel is used in a country that requires
decadic dialing as 60/40. This option has no effect
when using DTMF tone dialing.
12.4
Alarm Link Options
Location
180
1
Upload/download allowed
2
Callback phone number required for
upload/download
4
Exit upload/download connection on alarm
8
Reserved
For more information about this location, refer to
Section 8.2 Alarm Link Options on page 42.
13.0 Access Codes
This section describes the access codes used to assign
privileges and access functions for User Code holders
of the system. There are two types of access codes,
the Installer Code and User Codes. Each of these
codes allows specific access and operation of control
panel functions.
13.1
Installer Code
181 to 184
Location
Use this code to access Installer's Programming
Mode. The Installer Code can be up to four digits
long. After the control panel is powered up, the
Installer Code can disarm the system if it is the first
code used. The next time the Installer Code is used
enables access to Installer's Programming Mode.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Access Codes
Location
Default
181
1
182
2
183
3
184
4
Installer Code functions allow the installer to execute
functions when the system is disarmed without the
customer's Master Code. Refer to Section 6.1 Installer
Code Functions on page 28 for more information.
Refer to Section 2.1 Programming with the Remote
Codepad on page 10 for more information on
programming the system.
13.2
User Codes
The purpose of User Codes is to arm and disarm the
system and to perform other specific functions as
described in Section 6.2 Master Code Functions on page
33. A Master Code holder can change or delete User
Codes at any time.
User Codes 1 to 8 can be one to four digits long.
Each User Code has its own priority level. More than
one User Code can have the same priority level. The
priority level controls the behavior of the code, such
as allowing it to arm only, to arm and disarm, or
allow access to the Master Code functions. The
installer can assign access to Master Code functions
to multiple User Codes. The priority level for each
User Code is programmed in the last location of the
code.
Only the installer can change the priority
level.
Although 16 User Codes are available, User Codes 9
through 16 can only be Remote Radio User Codes.
Refer to Section 5.0 Remote Radio Transmitter Operations
on page 25 for more information.
User Code 16 is reported when any of these methods
is used to arm or disarm the system:
•
Arming and disarming using remote radio
control equipment connected to the RE005/E
2-Channel Radio Interface.
•
Arming and disarming using the CC816 Alarm
Link Software.
•
Arming remotely by telephone.
•
Single button arming in AWAY Mode, STAY
Mode 1, or STAY Mode 2.
•
Single button disarming from STAY Mode 1 or
STAY Mode 2.
•
Automatic arming in AWAY Mode or STAY
Mode 1.
•
Automatic disarming from AWAY Mode, STAY
Mode 1, or STAY Mode 2
13.2.1
ICP-CC408 User Codes
The ICP-CC408 Control Panel can have up to
sixteen programmable User Codes (1 to 16) to
operate the system. Refer to Section 4.0 System
Operations on page 19 for information about the
different methods to arm and disarm the system.
EN | 54
