ICP-CC408 | Installation Guide | 16.0
A Test Report (Contact ID Event Code 602) is a
specific signal sent to the base station receiver and is
normally used to test the dialing and reporting
functions of the control panel.
When programming Test Report options, specify the
hour and minute of the day the report is required,
and how often to send the report. Test reports are
reported on a daily basis from every day to every
fifteen days. Refer to Section 6.1.1 Set the Number of
Days until the First Test Report on page 29 to set the
first test report.
If Test Reports are not required, program
the repeat interval in Location 366 as 0.
Program the Test Report Time as 24:00
to send reports every 30 min.
Example
If you want to send Test Reports once every seven
days at 11:35 PM, program Locations 360 to 366 as:
[2 3 3 5 7 1 7]

15.22 Test Reporting Dialer Options

367
Location
0 No Codepad Alarm Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1 fails
This location is set by default to report only to
Receiver 1. You can select whether Test Reports are
sent to Receiver 1, Receiver 2, or both, Receiver 2
only when Receiver 1 fails, or there is no reporting at
all.

16.0 Programmable Outputs

The ICP-CC408 Control Panel has four fully-
programmable outputs on the main printed circuit
board and one programmable output that operates
the codepad buzzer. The four outputs are set by
default to operate as horn speaker, fire alarm
verification, strobe, and internal screamer.
Programmable outputs require four parameters to
operate correctly.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Programmable Outputs

Table 57: Output Parameters

Parameter
Event Type
Polarity
Time Base/
Time
Multiplier
Location 368 to 397
Output 1 (Default = Horn Speaker)
Time Base Multiplier
Time Base Multiplier
Output 2 (Default = Fire Alarm With Verification)
Time Base Multiplier
Time Base Multiplier
Strobe Output (Default = Strobe – Reset in 8 hours)
Time Base Multiplier
Time Base Multiplier
Description
The Event Type specifies when an output
is activated. The Output Event Types are
listed in Section 16.2 on page 69. Enter
the code for the Output Event Type into
the two corresponding locations for the
output.
Polarity determines whether the output
operates for the duration of the event,
pulses for the duration, operates once
only (one shot), or latches on. The Polarity
options are listed in Table 58 on page
74.
The Time Base and Time Multiplier
parameters determine how long and how
often the output operates. Refer to
Section 16.4 Output Timing on page 75.
Location
Event Code 368
Event Code 369
Polarity 370
Time Base 371
372
373
Event Code 374
Event Code 375
Polarity 376
Time Base 377
378
379
Event Code 380
Event Code 381
Polarity 382
Time Base 383
384
385
EN | 68
Default
1
14
0
0
0
0
2
7
10
2
1
3
6
0
6
4
0
8
