ICP-CC408 | Installation Guide | 16.0
12 – Normally Low, One-Shot Open with Reset
This one-shot polarity is normally 0 V and switches
to open circuit when the event occurs. Because the
output switches back to 0 V when the one-shot time
expires or when the event returns to normal, the one-
shot timer can be shortened regardless of the time
setting.
13 – Normally Low, One-Shot Open with Alarm
This one-shot polarity is normally 0 V and switches
to open circuit when the event occurs. Because the
output switches back to 0 V when the one-shot time
expires, when the event returns to normal, or when
the system is disarmed, the one-shot timer can be
shortened regardless of the time setting.
14 – Normally Low, Latching Open
This polarity is normally 0 V and switches to open
circuit when the event occurs. The output switches
back to 0 V when the user holds down [7] on the
remote codepad until two beeps sound. Time
parameters do not apply to this polarity.
16.4

Output Timing

The timing of outputs is calculated by the time base
and a multiplier. These two values play different
roles depending on the selected polarity. When you
program outputs to pulse, you can set both the On
and Off times. You can program one-shot polarities
to operate from 200 ms to 99 hours.
The maximum value you can program in
the two multiplier locations is 9,9.

Table 59: Time Base Settings

Option Description
1 200 ms
2 1 sec
3 1 min
4 1 hour
You can only set the time base settings to one of the
values listed in Table 59. The multiplier value is a
two-digit decimal number from 00 to 99. For greater
accuracy, use 60 sec for 1-min intervals and 60 min
for one-hour intervals.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Programmable Outputs
16.5

Pulsing Polarities

When programming pulsing polarities, you must set
both the On and Off times. The duration, or On
time, for an output is determined by time base
selected from one of the options in Table 59. In other
words, there are only four possible On times.
The Off time is calculated by multiplying the On
time by a decimal number between 00 and 99. If you
want an output to operate for 200 ms every 5 sec,
program the time settings as:
On Time: 1
Off Time: 2 5

Table 60: Pulsing Time Settings

On Time
200 ms
1 sec
1 min
1 hour
16.6

One-Shot Polarities

The duration, or On time, of an output is determined
by the product of the time base and the multiplier.
If you want an output to operate for 5 sec, program
the time settings as:
Time Base: 2
Multiplier: 0 5
The On time is calculated by multiplying the time
base setting (1 sec) by the multiplier value (05) (for
example, 1 x 05 = 5 sec).

Table 61: One-Shot Time Settings

On Time
200 ms to 19.8 sec
1 to 99 sec
1 to 99 min
1 to 99 hr
Off Time Increments
200 ms to 200 ms
19.8 sec
1 to 99 sec 1 sec
1 to 99 min 1 min
1 to 99 hr 1 hr
Increments Tolerance
200 ms ±200 ms
1 sec ±1 sec
1 min ±1 min
1 hr ± hour
EN | 75
Tolerance
±200 ms
±1 sec
±1 min
± hr
