ICP-CC408 | Installation Guide | 10.0

Table 43: 4 + 2 Reporting Format

New Event 4 + 2 Report
Alarm SSSS AC
Trouble SSSS TC
Bypass SSSS BC
AC Fail SSSS EA
Low Battery SSSS LL
Opening Report SSSS OU
Closing Report SSSS CU
Test Report SSSS T
Program Altered SSSS P0
Duress SSSS DD
Event 4 + 2 Report
Alarm Restore SSSS R C
Trouble Restore SSSS TR C
Bypass Restore SSSS B
AC Fail Restore SSSS E
Low Battery SSSS L L
Low Battery Restore SSSS L
Table 44: 4 + 2 Transmission Code
Descriptions
Code Description
SSSS Subscriber ID Number
A Alarm
C Channel Number
H
0 Zero
T Trouble
B Bypass
E AC Fail Code 1
AC AC Fail Code 2
L Low Battery Code 1
L Low Battery Code 2
B
O Open
C Close
U User Number
R Alarm Restore Code
TR Trouble Restore Code
B Bypass Restore Code
R
E AC Fail Restore Code 1
R
AC AC Fail Restore Code 2
R
L Low Battery Restore Code 1
R
L Low Battery Restore Code 2
BR
D Duress Code 1
D Duress Code 2
0
P Panic Code 1
P Panic Code 2
CH
T Test Code
E
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Dialer Reporting Formats
H
H
H
C
B
O
E
0
H
H
C
R H
A
R CR
B
BR
st
digit
nd
digit
st
digit
nd
digit
st
digit
nd
digit
st
digit
nd
digit
st
digit
nd
digit
st
digit
nd
digit
10.1.4

Basic Pager Reporting Format

Although Basic Pager Format requires some
interpretation of the numbers that appear on the
display, it is possible to differentiate between 1000
different control panels if a number of control panels
report to the one pager.
To set up Receiver 1 for basic pager reporting:
1. Program the Basic Pager's access telephone
number in Locations 000 to 015 (refer to Section
11.1 Primary Telephone Number for Receiver 1 and
Receiver 2 on page 49).
2. Program the Subscriber ID Number in Locations
034 to 039 (refer to Section 11.5 Subscriber ID
Number for Receiver 1 and Receiver 2 on page 50).
3. Select the Pager Handshake option (5) in
Location 032 (refer to Section 11.3 Handshake Tone
for Receiver 1 and Receiver 2 on page 50).
Program the Basic Pager Format option (5) in
Location 033 (refer to Section 11.4 Transmission Format
for Receiver 1 and Receiver 2on page 50).
To set up Receiver 2 for basic pager reporting:
1. Program the Basic Pager's access telephone
number in Locations 040 to 055 (refer to Section
11.1 Primary Telephone Number for Receiver 1 and
Receiver 2 on page 49).
2. Program the Subscriber ID Number in Locations
074 to 079 (refer to Section 11.5 Subscriber ID
Number for Receiver 1 and Receiver 2 on page 50).
3. Select the Pager Handshake option (5) in
Location 072 (refer to Section 11.3 Handshake Tone
for Receiver 1 and Receiver 2 on page 50).
4. Program the Basic Pager Format option (5) in
Location 073 (refer to Section 11.4 Transmission
Format for Receiver 1 and Receiver 2 on page 50).
The example in Figure 7 on page 48 shows:
•
Transmission from Subscriber ID Number 5678
•
Zone 2 is in alarm
•
Zone 3 is manually isolated
•
The system is armed
•
The Panic Zone is normal
•
The AC is connected
There is no fault condition.
EN | 45
