ICP-CC408 | Installation Guide | 10.0
10.2

Basic Pager Display Information

The Pager format supports only eight
zones.
Subscriber ID Number
This is the identification number of the control panel
and is programmed in Locations 034 to 039 for
Receiver 1 and Locations 074 to 079 for Receiver 2
(refer to Section 11.5 Subscriber ID Number for Receiver 1
and Receiver 2 on page 50). The pocket pager displays
only the last three digits of the Subscriber ID
Number.
Zone Status
The zone status display shows you the status of each
zone (1 to 8) of the control panel. Table 45 describes
each status number when displayed on a pocket
pager.

Table 45: Zone Status Display Descriptions

Status Zone Description
0 Zone normal
The zone is sealed.
1 Alarm
The zone is unsealed and in alarm.
2 Zone bypassed
A system operator manually isolated the
zone. Refer to Section 4.11 Isolating
on page 23
Zones
manually isolate a zone(s) prior to arming
the system Refer to Section 15.1 Zone
Status – Bypass Reports
more information.
3 Zone trouble
A zone was left unsealed after the end of
Exit Time. Refer to Section 15.2 Zone
Status – Trouble Reports
more information.
System Status
The system status information is shown by four
digits, which are defined in Figure 7 on page 48. The
first digit indicates whether the system is armed or
disarmed. The second digit indicates whether a
codepad alarm was activated by the operator (refer to
Section 4.7 Codepad Duress Alarm on page 22 through
Section 4.10 Codepad Medical Alarm on page 22 for
more information). The third digit indicates the status
of the AC MAINS supply. The fourth digit indicates
whether a system fault occurred at the control panel
(refer to Section 4.12 Fault Analysis Mode on page 23
for more information).
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Dialer Reporting Formats
for information about
on page 64
for
on page 64
for
EN | 46
