ICP-CC408 | Installation Guide | 9.0
If this option is not selected, the installer can connect
to a customer's control panel from any remote
location for upload/download operations without the
control panel calling back to the remote computer,
and the customer can initiate a modem call from the
codepad by holding down [6]. Refer to Section 8.0
Alarm Link Software on page 41 for more information.
4 – Terminate Alarm Link Connection on Alarm
If an alarm occurs when the control panel is
communicating with a remote computer using the
CC816 Alarm Link Software, the Alarm Link session
is terminated and the relevant alarm message is
transmitted to the base station receiver.
If an alarm occurs that does not have to be reported
to the base station receiver, the session is not
terminated. If this option is not selected and an alarm
occurs, the Alarm Link software prompts the
operator with a Terminate or Continue message.
9.0 Domestic Dialing
The locations of the primary and secondary
telephone numbers for Receiver 1 or Receiver 2 are
used only for base station and pager reporting. When
either Receiver 1 or Receiver 2 is set up for domestic
reporting, both the primary and secondary telephone
numbers are ignored.
The domestic dialing telephone numbers are stored
separately in Locations 466 to 513, which can store
up to 48 digits. These 48 locations can store one or
more telephone numbers. Depending on the length
of each telephone number, it is possible to store four
or more different telephone numbers for domestic
dialing.
If both Receiver 1 and Receiver 2 are set up for
domestic reporting format, you still have 48 data
locations. Both Receiver 1 and Receiver 2 use the
same domestic telephone numbers. Programming
separate domestic telephone numbers for Receiver 1
and Receiver 2 is not available for domestic dialing
format.
Refer to Section 9.2 Setting Up and Programming
Domestic Reporting on page 43 for more information.
9.1
Domestic Dialing Function
When the control panel is activated into alarm, it
dials the first programmed telephone number. If a
busy or engaged tone is detected, the control panel
hangs up and dials the second telephone number (if
one is programmed). The first call is counted as one
unsuccessful dialing attempt. If the second telephone
number is also busy or an engaged tone is detected,
the control panel hangs up and dials the third
telephone number (if one is programmed) or
attempts the first telephone number again.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Domestic Dialing
If a busy tone is not detected, the control panel
assumes that the telephone was answered and sends
its transmission. The transmission sequence consists
of an identification beep, followed by a siren tone
and a long pause. The transmission sequence is
repeated until the control panel receives an
acknowledgment tone during the pause. The control
panel automatically hangs up after 2 min. If more
than one control panel reports to the same telephone
number, the identification beep allows the customer
to verify the control panel that called. The
identification beep is programmed in Location 039 of
the Subscriber ID Number for Receiver 1 or
Location 079 of the Subscriber ID Number for
Receiver 2.
When set up for Domestic Dialing
Format, the control panel attempts a
maximum of six calls per alarm event. This
count includes any unsuccessful calls.
The counter is reset if the zone is
reactivated and the control panel
attempts additional six calls. The control
panel stops dialing after six attempts or
three successful calls. The control panel
also stops dialing if a valid User Code is
entered at the remote codepad.
If both Receiver 1 and Receiver 2 are
programmed for domestic dialing, the
maximum number of calls per alarm event
is twelve.
To acknowledge domestic dialing:
If the received call is not acknowledged during any
of the transmission pauses by pressing the [*] button
on a touch-tone telephone, the control panel
continues to send its transmission for two min. It then
hangs up and dials the next telephone number. If the
call is successfully acknowledged, the control panel
hangs up and makes no more calls for that event.
9.2
Setting Up and Programming
Domestic Reporting
Programming the control panel for domestic
reporting is extremely simple when using the
Installer's Programming Command 965. Refer to
Section 2.4.7 Command 965 – Set Up Domestic Dialing
Format on page 13 for more information.
To set up the control panel for domestic dialing:
1. Enter the Installer Code and press [AWAY] to
enter Installer's Programming Mode.
Two beeps sound and the STAY and AWAY
indicators flash.
2. Enter [9 6 5] and press [AWAY].
Two beeps sound. The control panel is now set
up for Domestic Dialing Format.
EN | 43
