NB3710
User Manual for NRSW version 4.4
Feature
Speed
Current
Max. cable length
Cable shield
Connector type

3.4.8. M12 Ethernet Connectors

Specification
The five Ethernet ports have following specification:
Feature
Isolation to enclosure
Speed
Mode
Crossover
Max. cable length
Cable type
Cable shield
Connector type
Specification
Low, Full & Hi-Speed
max. 500 mA
3 m
mandatory
Type A
Table 3.12.: USB 2.0 Host Port Specification
Specification
1500 V
10/100 Mbit/s
Half- & Full-Duplex
Automatic MDI/MDI-X
100 m
CAT5e or better
mandatory
M12 d-coded
Table 3.13.: Ethernet Port Specification
