5.4.8. BGP

The BGP tab allows to set up peerings of the NetModule router with other Border Gateway Protocol
enabled routers.
Parameter
BGP status
AS number
Redistribute connected
routes
Redistribute local routes
Redistribute OSPF routes
Disable BGP when VRRP
slave
The neighbors tab is used to configure all the BGP routers to peer with.
Parameter
IP address
As number
Password
Multihop
The Networks tab allows to add IP network prefixes that shall be distributed via BGP in addition to the
networks that are redistributed from other sources as defined on the general tab.
Parameter
Prefix
Prefix length
BGP General Settings
Specifies whether the BGP routing protocol is active
The number of the autonomous system to which the NetModule router
belongs (1-4294967295)
Redistribute routes to networks which are directly connected to the
NetModule router
Redistribute routes from the NetModule router's own routing table
Redistribute routes learned via the OSPF routing protocol
Disables the BGP protocol when the router is set to slave mode by
the VRRP redundancy protocol
BGP Neighbors
IP address of the peer router
Autonomous system number of the peer router (1-4294967295)
Password for authentication with the peer router. If left blank authen-
tication is disabled.
Allow multiple hops between this router and the peer router instead of
requiring the peer to be directly connected.
BGP Networks
Prefix of the network to be distributed
Length of the prefix to be distributed
