Ethernet Link Settings - NetModule NB3710 User Manual

NB3710
User Manual for NRSW version 4.4

Ethernet Link Settings

HOME INTERFACES
WAN
Link Management
Supervision
Settings
Ethernet
Port Setup
VLAN Management
IP Settings
Mobile
Modems
SIMs
Interfaces
WLAN
Administration
Configuration
IP Settings
Bridges
USB
Serial
Digital I/O
GNSS
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
Link negotiation can be set for each Ethernet port individually. Most devices support auto-negotiation
which will configure the link speed automatically to comply with other devices in the network. In case
of negotiation problems, you may assign the modes manually but it has to be ensured that all devices
in the network utilize the same settings then.
VLAN Management
NetModule routers support Virtual LAN according to IEEE 802.1Q which can be used to create virtual
interfaces on top of an Ethernet interface. The VLAN protocol inserts an additional header to Ethernet
frames carrying a VLAN Identifier (VLAN ID) which is used for distributing the packets to the associated
virtual interface. Any untagged packets, as well as packets with an unassigned ID, will be distributed
to the native interface.
ROUTING FIREWALL VPN SERVICES
Port Assignment Link Settings
Link speed for Ethernet 1:
Link speed for Ethernet 2:
Apply
Figure 5.7.: Ethernet Link Settings
55
SYSTEM
auto-negotiated
auto-negotiated
LOGOUT
