NB3710
User Manual for NRSW version 4.4

3.4.6. GNSS

GNSS (Option G)
The GNSS is used from a WWAN Module.
Feature
Systems
Data stream
Tracking sensitivity
Supported antennas
GNSS (Option Ge)
The GNSS module supports Dead Reckoning with onboard 3D accelerometer and 3D gyroscope.
Feature
Systems
Data stream
Tracking sensitivity
Channels
Accuracy
Supported antennas
The GNSS antenna port have the following specification:
Feature
Max. allowed cable length
Max. allowed antenna gain
Min. distance between collocated ra-
dio transmitter antennas
(Example: WLAN1 to MOB1)
Connector type

3.4.7. USB 2.0 Host Port

The USB 2.0 host port has the following specification:
Specification
GPS/GLONASS
JSON or NMEA
-154 dBm
Active and passive
Table 3.9.: GNSS Specifications option G
Specification
GPS/GLONASS/BeiDu/Galileo ready
NMEA or UBX
-160 dBm
72
2m
Active and passive
Table 3.10.: GNSS Specifications option Ge
Specification
30 m
3.0 dBi
20 cm
TNC
Table 3.11.: GNSS / GPS Antenna Port Specification
