NB3710
User Manual for NRSW version 4.4
Position
This pages provides further information about the satellites in view and values derived from them:
Parameter
Latitude
Longitude
Altitude
Satellites in view
Speed
Satellites used
Dilution of precision
Furtheron, each satellite also comes with the following details:
Parameter
PRN
Elevation
Azimuth
SNR
Please note that the values are shown as calculated by the daemon, their accuracy might be sugges-
tive.
Supervision
Parameter
Administrative status
Mode
Max. downtime
Emergency action
GNSS Information
The geographic coordinate specifying the north-south position
The geographic coordinate specifying the east-west position
The height above sea level of the current location
The number of satellites in view as stated in GPGSV frames
The horizontal and vertical speed in meter per second as stated in
GPRMC frames
The number of satellites used for calculating the position as stated in
GPGGA frames
The dilution of precision as stated in GPGSA frames
GNSS Satellite Information
The PRN code of the satelitte (also referred as satellite ID) as stated
in GPGSA frames
The elevation (up-down angle between the dish pointing direction) in
degrees as stated in GPGSV frames
The azimuth (rotation around the vertical axis) in degrees as stated in
GPGSV frames
The SNR (Signal to Noise Ratio), often referred as signal strength
GNSS Supervision
Enable or disable GNSS supervision
Specifies whether to monitor the NMEA stream or GPS fixes
The period of time without valid NMEA stream or GPS fix after which
an emergency action shall be taken
The corresponding emergency action. You can either let just restart
the server, which will also re-initialize the GPS function on the module,
or reset the module in severe cases. Please note that this may have
effects on any running WWAN/SMS services.
