NB3710
User Manual for NRSW version 4.4
Parameter
Alias subnet mask
When running in WAN mode, the interface may be configured with the following settings:
Parameter
WAN mode
MTU
When running as DHCP client, no further configuration is required because all IP-related settings
(address, subnet, gateway, DNS server) will be retrieved from a DHCP server in the network. You
may also define static values but caution has to be taken to assign an unique IP address as it would
otherwise raise IP conflicts in the network.
PPPoE is commonly used when communicating with another WAN access device (like a DSL modem).
The following settings can be applied:
Parameter
User name
Password
Service name
Access concentrator name
LAN IP Settings
The alias subnet mask for this interface
WAN IP Settings
The WAN operation mode, defines whether the interface should run
as DHCP client, statically configured or over PPPoE.
The Maximum Transmission Unit for the interface, if provided it will
specify the largest size of a packet transmitted on the interface.
PPPoE Configuration
PPPoE user name for authenticating at the access device
PPPoE password for authenticating at the access device
Specifies the service name set of the access concentrator and can
be left blank unless you have multiple services on the same physical
network and need to specify the one you want to connect to.
The name of the concentrator (the PPPoE client will connect to any
access concentrator if left blank)
