NB3710
User Manual for NRSW version 4.4
Parameter
Ports
Redirect to
Redirect port
Select mapping context according to your needs:
Parameter
host
network
port range
NAPT Outbound Rules
Outbound rules will modify the source section of IP packets and can be used to establish 1:1 NAT
mappings but also to redirect packets to a specific service.
Parameter
Description
Outgoing interface
Target
Source address
Protocol
Ports
Rewrite source address
Rewrite source port
Inbound NAPT Rules
The used UDP/TCP port of matching packets
The address to which matching packets shall be redirected
The port to which matching packets will be redirected
Mapping contexts
Rewrite destination address and port for one given host (i.e.
10.0.0.1:8080 192.168.1.100:80
Rewrite destination address for a full network (i.e. 10.0.0.0/24
192.168.1.0/24
Rewrite destination address and port based on the incoming port
(i.e. 10.0.0.1:22000-22255
responding rule for port range translation in outbound rules. Use net-
work based mapping there.
Outbound NAPT Rules
A meaningful description of this rule
The outgoing interface on which matching packets are leaving the
router
The target address or network to which matching packets are des-
tined
The source address of matching packets (optional)
The used protocol of matching packets
The used UDP/TCP port of matching packets
The address to which the source address of matching packets shall
be rewritten
The port to which the source port of matching packets shall be rewrit-
ten
107
192.168.1.0/24:22). There is no cor-
