Feature
Systems
Data stream
Tracking sensitivity
Supported antennas
GNSS (Option Ge)
The GNSS module supports Dead Reckoning with onboard 3D accelerometer and 3D
gyroscope.
Feature
Systems
Data stream
Tracking sensitivity
Channels
Accuracy
Supported antennas

3.3.5. USB 2.0 Host Port

The USB 2.0 host port has the following specification:
Feature
Speed
Current
Table 3.7.: USB 2.0 Host Port Specification

3.3.6. M12 Ethernet Connectors

Specification
The five Ethernet ports have following specification:
NB3710 User Manual 4.0
Specification
GPS/GLONASS
JSON or NMEA
-154 dBm
Active and passive
Table 3.5.: GPS Specifications
Specification
GPS/GLONASS/BeiDu/Galileo ready
NMEA or UBX
-160 dBm
72
2m
Active and passive
Table 3.6.: GNSS Specifications
Specification
Low, Full & Hi-Speed
max. 500 mA
