NB2800 Overview
1
LED
2
USB
3
SIM slots
www.netmodule.com
Status indicator.
- STAT blinking: The device is busy due to startup,
software or configuration update.
- STAT on: The device is ready.
USB 3.0 host port
Slots for 4 Micro SIM cards (3FF). SIM cards can be
inserted by sliding it into one of the designated slots on
the front panel. Push the SIM cards with the chip facing
down using a small paper clip (or similar) until they snap
into place:
8/7/2017 © NetModule AG | Errors reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NetModule NB2800
Summary of Contents for NetModule NB2800
- Page 1 Push the SIM cards with the chip facing down using a small paper clip (or similar) until they snap into place: www.netmodule.com 8/7/2017 © NetModule AG | Errors reserved...
- Page 2 For power, use the pins 1 (V ) and 2 (V+). For ignition sense, use pin 3 (IGN). Extension Connector for extensions. Please find detailed port cover information in the router manual. www.netmodule.com 8/7/2017 © NetModule AG | Errors reserved...
