In case an interface has been activated, the system will automatically create the following queues:
Parameter
high
default
low
Each queue can be configured as follows:
Parameter
Name
Priority
Bandwidth
Set TOS
You can now configure and assign any services to each queue. The following parameters apply:
Parameter
Interface
Queue
Source
Destination
Protocol
Source Port
Destination Port
Type of Service
QoS Default Queues
A high priority queue which may hold any latency-critical services
(such as VoIP)
A default queue which will handle all other services
A low priority queue which may hold less-critical services for which
shaping is intended
QoS Queue Parameters
The name of the QoS queue
A numerical priority for the queue, lower values indicate higher priori-
ties
The maximum possible bandwidth for this queue in case the total
bandwidth of all queues exceeds the set upstream bandwidth of "QoS
Interface Parameters"
The TOS/DiffServ value to set on matching packets
QoS Service Parameters
The QoS interface of the queue
The QoS queue to which this service shall be assigned
Specifies a network address and netmask used to match the source
address of packets
Specifies a network address and netmask used to match the destina-
tion (target) address of packets
Specifies the protocol for packets to be matched
Specifies the source port for packets to be matched
Specifies the destination port for packets to be matched
Specifies the TOS/DiffServ for packets to be matched
