3.4.7. USB 2.0 Host Port

The USB 2.0 host port has the following speci cation:
Feature
Speed
Current
Max. cable length
Cable shield
Connector type

3.4.8. M12 Ethernet Connectors

Speci cation
The Ethernet ports have following speci cation:
Feature
Isolation to enclosure
Speed
Mode
Crossover
Max. cable length
Cable type
Cable shield
Connector type
NB3000-Line-Hd User Manual 4.2
Speci cation
Low, Full & Hi-Speed
max. 500 mA
3 m
mandatory
Type A
Table 3.12.: USB 2.0 Host Port Speci cation
Speci cation
1500 V
Fast Ethernet: 10/100 Mbit/s
Gigabit Ethernet: 10/100/1000 Mbit/s
Half- & Full-Duplex
Automatic MDI/MDI-X
100 m
CAT5e or better
mandatory
Fast Ethernet: M12 d-coded
Gigabit Ethernet: M12 x-coded
Table 3.13.: Ethernet Port Speci cation
