NB3710
User Manual for NRSW version 4.4

5.2. HOME

This page provides a status overview of enabled features and connections.

HOME

INTERFACES
Status
Summary
WAN
WWAN
WLAN
GNSS
Ethernet
LAN
Bridges
DHCP
OpenVPN
IPsec
PPTP
MobileIP
Firewall
System
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
Summary
This page offers a short summary about the administrative and operational status of the router's inter-
faces.
WAN
This page offers details about any enabled Wide Area Network (WAN) links (such as the IP addresses,
network information, signal strength, etc.) The information about the amount of downloaded/uploaded
data is stored in non-volatile memory, thus survive a reboot of the system.
The counters can be reset by pressing the Reset button.
WWAN
This page shows information about modems and their network status.
WLAN
The WLAN page offers details about the enabled WLAN interfaces when operating in access-point
mode. This includes the SSID, IP and MAC address and the currently used frequency and transmit
ROUTING FIREWALL VPN SERVICES
Summary
Description
LAN2
WWAN1
WLAN1
IPsec1
PPTP1
MobileIP
Figure 5.2.: Home
45
SYSTEM
Administrative Status Operational Status
enabled dialing
enabled down
enabled, access-point up
enabled down
enabled, server up
enabled down
LOGOUT
