5.3.4. WLAN

WLAN Management

In case your router is shipping with a WLAN (or Wi-Fi) module you can operate it either as client,
access point, mesh point or certain dual modes. As a client it can create an additional WAN link
which for instance can be used as backup link. As access point, it can form another LAN interface
which can be either bridged to an Ethernet-based LAN interface or create a self-contained IP interface
which can be used for routing and to provide services (such as DHCP/DNS/NTP) in the same way like
an Ethernet LAN interface does. As mesh point, it can create a wireless mesh network to provide a
backhaul connectivity with dynamic path selection. As dual mode, it is possible to run access point
and client or mesh point and access point functionality on the same radio module.
HOME INTERFACES
WAN
Link Management
Supervision
Settings
Ethernet
Port Setup
VLAN Management
IP Settings
Mobile
Modems
SIMs
Interfaces
WLAN
Administration
Configuration
IP Settings
Bridges
USB
Serial
Digital I/O
GNSS
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
If the administrative status is set to disabled, the module will be powered off in order to reduce the
overall power consumption. Regarding antennas, we generally recommend using two antennas for
better coverage and throughput. A second antenna is definitely mandatory if you want to achieve
higher throughput rates as in 802.11n.
A WLAN client and a mesh point will automatically became a WAN link and can be managed as
described in chapter 5.3.1.
ROUTING FIREWALL VPN SERVICES
WLAN Management
Administrative status:
Operational mode:
Regulatory domain:
Operation type:
Radio band:
Bandwidth:
Channel:
Number of antennas:
Antenna gain:
Apply Continue
Figure 5.12.: WLAN Management
64
SYSTEM
enabled
disabled
client
access point
mesh point
dual modes
European Union
802.11b
2.4 GHz
20 MHz
Auto Channel utilisation
2
0 dB
