In order to form a distinctive subnet, the network interface of a remote LAN host must be configured
with the same VLAN ID as defined on the router. Further, 802.1P introduces a priority field which
influences packet scheduling in the TCP/IP stack.
The following priority levels (from lowest to highest) exist:
Parameter
0
1
2
3
4
5
6
7
ROUTING FIREWALL VPN SERVICES
VLAN Management
VLAN
ID Network Interface
Interface
LAN1-1 1 LAN1
LAN1-2 5 LAN1
Figure 5.8.: VLAN Management
VLAN Priority Levels
Background
Best Effort
Excellent Effort
Critical Applications
Video (< 100 ms latency and jitter)
Voice (< 10 ms latency and jitter)
Internetwork Control
Network Control
