4.5. Installation of the Local Area Network

Up to five 10/100 Mbps Ethernet devices can be directly connected to the router, further devices can
be attached via an addtional Ethernet switch. Please ensure that the connector has been plugged
in properly and remains in a fixed state, you might otherwise experience sporadical link loss during
operation. The Link/Act LED will lit up as soon as the device has synced. If not, it might be necessary
to configure a different link setting as described in chapter 5.3.2. By default, the router is configured
as a DHCP server and has the IP address 192.168.1.1.
Attention:
Only a shielded Ethernet cable may be used.

4.6. Installation of the Power Supply

The router can be powered with an external source supplying between 12 V
used with a certified (CE or equivalent) power supply, which must have a limited and SELV circuit out-
put. The router is now ready for getting engaged.
Attention: Only CE-compliant power supplies with a current-limited SELV output volt-
age range (for NetModule routers with "Pb" option with a correspondingly higher output
voltage range and in accordance with appropriate comparable safety precautions) may
be used with the NetModule routers
40
and 48 V . It is to be
DC DC
