Chapter 11 External Pacing

Pediatric Pacing

Noninvasive pacing of pediatric patients is performed in an identical manner to adult pacing.
Smaller size pediatric therapy electrodes are available for patients weighing less than
33 lbs/15 kg. If it is necessary to pace for more than 30 minutes, periodic inspection of the
underlying skin is strongly advised. Carefully follow all instructions on electrode packaging.

Pacing Messages

The ZOLL M2 unit may display the following messages when pacing.
System Message
4:1 MODE FAILED
4:1 SELECTED
ATTACH PADS
CHECK PADS--PADS SHORTED
CONNECT THERAPY CABLE
DEMAND PACING DISABLED
ECG LEAD OFF
PACER DISABLED
RELEASE 4:1 BUTTON
SET PACER OUTPUT MA
USE PADS TO PACE
11-10
Description
The 4:1 quick access key was pressed while
the unit was not actively pacing.
The 4:1 function is activated while the unit is
in Pacer mode.
Therapy pads are not connected or are not
making good contact with the patient. Apply
therapy pads to the patient.
The pacer output is short circuited due a test
plug connection or a device/MFC fault. Check
the pads connection.
The MFC cable is disconnected from the unit
while the unit is in Pacer mode.
Demand pacer function disabled due to
self-test failure.
One or more leads is not connected to the
patient or to the ZOLL M2 unit. If the ECG
lead displayed in the primary waveform is off,
the pacer is pacing in Fixed mode.
Pacer function disabled due to self-test
failure.
The 4:1 quick access key was pressed while
switching to Pacer mode.
The pacer output is 0 mA after switching to
Pacer mode.
The paddles are connected to the unit when in
Pacer mode.
