5.1 Periodic Replacement Parts

5.1.1 Periodic Replacement Parts

5.2 Consumable Parts

5.2.1 Consumable Parts
Service MAINTENANCE KIT Wia
MAINTENANCE KIT CR
WASTE INK ABSORBER UNIT
WASTE INK ABSORBER UNIT (L)
WASTE INK ABSORBER UNIT (S)
SUCTION FAN UNIT
DUCT
CARRIAGE UNIT
MOUNT, SENSOR ADJUSTING
SCALE, LINEAR
TUBE UNIT
MULTI SENSOR UNIT
PURGE UNIT
HEAD MANAGEMENT SENSOR
MOTOR, CARRIAGE
FEED MOTOR ASS'Y
FAN UNIT
User See "Product Overview> Features> Consumables"
After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service mode to initialize (clear) the parts counter information.
Level
User None
Service Personnel None
Consumables
Name Part number
QY6-1528
QY6-1529
QL2-2110
QL2-2108
QL2-1650
QM3-3069
QL2-1663
QM4-8199
QL2-8099
QC3-1877
QM4-8201
QM4-8018
QM3-7018
QM3-1056
QK1-2868
QM4-8113
QM3-7025
Periodic Replacement Part
Life sheets/
Q'ty PARTS xx
A0
1 20000 Wia
1 20000 CR-1/CR-4
1 20000 Wia-1
2 20000 Wia-3/Wia-4
1 20000 Wia-5
1 20000 Wia-6
1 20000
1 20000 CR-1/CR-2/
CR-3
1 20000 CR-1/CR-2/
CR-3/CR-5
1 25000 CR-2
1 20000 CR-4
1 20000 CR-5
MS-1
1 25000 PG-1
1 50000 HMa-1
1 28000 PL-1
1 50000 PS-1
2 50000 Mi-1
Chapter 5
Service Mode
States (Error Code)
OK/W1/E146-4001
OK/W1/W2
OK/W1/E144-4047
OK/W1/W2
OK/W1/E141-4046
OK/W1/W2
OK/W1/E146-4001
0012-6595
0028-9793
5-1
