Canon imagePROGRAF IPF8400 Service Manual page 293

Display message
Top paper feed slot is selected.
Press OK and load a sheet.
Sheet printing is selected.
Press Load/Eject and load sheets.
Remove the cut sheets.
Roll printing is selected, but sheets are
loaded.
Press OK, remove the sheets, and load a
roll.
This type of media is not
compatible with HP-GL/2.
! Cannot print as selected.
Another roll is in use.
Stop: Stop Printing
! Cannot print as selected.
Another roll is in use.
Stop: Stop Printing
Borderless printng not possible.
Check roll position.
Online: Print
Load/Eject: Change Paper
Borderless printng not possible.
Check paper size setting.
Borderless printng not possible.
Paper stretched or shrank.
Confirm usage cond. of the paper.
Borderless printng not possible.
Check supported paper.
Insufficient paper for job
Online: Print
Stop: Stop Printing
Load/Eject: Change Paper
Insufficient paper for job
Insufficient paper for job
Cannot adjust printhead.
Press Online to clear the error and
readjust printhead.
Cannot adjust printhead.
Press Online to clear the error and
readjust printhead.
Cannot adjust eccentric.
Press Online to clear the error.
Cannot adjust optic axis.
Press Online to clear the error.
LFNG XXX XXX XXX XXX
press OK key
CR MOTOR TUNING
ERROR :PRESS OK
CR VIBRATION
ERROR :PRESS OK
CRNG XXX XXX XXX XXX
press OK key
! Cannot calibrate.
Press OK and try calibration again.
Error! E02827
Cannot adjust.
Code* Condition detected
03860002-2E02 Data with a cut sheet specification has been
received but no cut sheets are loaded.
03860002-2E05 Manual feed paper setting job has been
received, but no manual feed paper is
loaded.
03860002-2E07 Waiting for manual feed paper to be
removed.
03860002-2E0A Data with a roll media specification has
been received when a cut sheet tray is
loaded.
03860006-2825 Paper type mismatch at HP-GL/2 printing Exchange for the compatible paper to HP-GL/2 before
03860007-2E40 Lower roll data has been received when
there is print in the upper roll.
03860007-2E41 Lower roll data has been received when
there is print in the lower roll.
03861001-2405 Paper loaded at a position inaccessible for
borderless printing
03861001-2406 Data unfit for borderless printing
03861001-2407 Borderless printing disabled (engine
detection)
03861001-2408 Borderless printing disabled (unsupported
size)
03862000-2E09 Not enough roll media on remaining roll
media quantity detection
03862001-2E31 Not enough roll media
03862002-2E32 Not enough roll media (lower roll)
03863000-2820 Printhead registration unadjustable
03863000-2821 LF unadjustable
03863000-2822 Eccentricity correction disabled
03863000-2824 Optical axis error
03863000-2826 Eccentricity correction error
03863000-282A Carriage identification process NG
Carriage identification process failed.
For service mode.
03863000-282B Carriage abnormal vibration error
Carriage vibration was detected when
performing carriage identification process.
For service mode.
03863000-2831 Printhead registration unadjustable (when
performing CR REG).
03863000-2F34 Color calibration adjustment failure error
03863000-4034 Sensor calibration error
Action
Load cut sheets at the paper tray port.
Load cut sheet in the manual feed paper slot.
Remove the cut sheet.
Replace with roll media.
reprinting.
Press the Stop button to delete the print job.
Press the Stop button to delete the print job.
Check to see if a borderless printing spacer is installed.
Reload the paper.
Check the data, and then print again.
Reload the paper.
Check the media size.
Renew the supply of roll media.
Renew the supply of roll media.
Renew the supply of roll media.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Check to see if paper has not jammed.
Check the multi sensor.
Check the head management sensor.
Check to see if paper has not jammed.
Press the OK button to clear the error.
It may essentially be a sensor failure, and the similar
error might be repeated.
Press the OK button to clear the error.
It may essentially be a sensor failure, and the similar
error might be repeated.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Perform calibration again, and if the same error occurs,
replace the multisensor.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Chapter 8
8-15
